SKU
BCM957412N4120C
Category
Network Interface Cards
Overview
The Broadcom® BCM957412N4120C is a dual-port 10 Gb/s PCI Express 3.0 x8 network adapter designed to the Open Compute Project (OCP) 3.0 Design Specification in small form factor with two SFP+ network connectors. The adapter supports SFP+ optical modules and copper directattach cables. The network adapter uses the Broadcom BCM57412 25GbE MAC controller with an integrated dual-channel 10GbE SFI transceiver.
Features
• Dual-port pluggable media interface, which can connect to a 10G SFP+ optical transceiver or a copper directattach cable.
• Fully compliant with the SFF-8402 standard.
• x8 PCI Express 3.0 compliant.
• SR-IOV with up to 128 virtual functions (VFs).
• Function-Level Reset (FLR) support.
• TruFlow? flow processing engine.
• Virtual Network Termination-VXLAN, NVGRE, Geneve, GRE encap/decap.
• vSwitch Acceleration.
• Tunnel-aware stateless offloads.
• DCB support - PFC, ETS, QCN, DCBx.
• RDMA over Converged Ethernet (RoCE).
• Network Controller Sideband Interface (NC-SI).
• SMBus 2.0.
• MCTP over SMBus.
• PCIe-based UART and KCS.
• Jumbo frames up to 9 KB.
• Advanced congestion avoidance.
• Multiqueue, NetQueue, and VMQ.
• IPv4 and IPv6 offloads.
• TCP, UDP, and IP checksum offloads.
• Large send offload (LSO).
• Large receive offload (LRO).
• TCP segmentation offload (TSO).
• Receive-side scaling (RSS).
• Transmit-side scaling (TSS).
• VLAN insertion/removal.
• Interrupt coalescing.
• Network boot-PXE, UEFI.
• iSCSI boot.
• Wake-on-LAN (WOL).
• MSI and MSI-X.
• Conforms to the OCP 3.0 Design Specification Version 1.00.
Applications
• Dual-port 10-Gigabit Ethernet adapter for OCP systems.
Highlights
10Gigabit Ethernet Card guarantees a replacement networking interface to client, server or workstation
This 8000 MB/s bandwidth PCI Express 3.0 x8 adapter ensures easy connectivity and plug-in form-factor for affordable and reliable Ethernet network
For high bandwidth connectivity, add this efficient dual port 10gigabit ethernet card to your server or workstation
Supports optical fiber cable to span longer distances and provides data transmission rates par excellence between servers and network components
With the 10GBase-X technology get up to 10Gbps data transfer rate over the supported network cable
