Genuine Black Box through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
AEMEX-HDMI-R2
Category
Video Processing/Capturing Modules
Overview
• Supports HDMI, 3.5-mm analog audio, and TOSLINK optical audio inputs and outputs.
• Supports resolutions of up to 4K at 60 Hz in 4:4:4 color.
• Embeds audio from either a 3.5-mm or optical source to an HDMI or DVI-D signal.
• Create audio channels where there was not an existing one.
• De-embed audio from HDMI signal and output it to 3.5-mm analog or digital optical sound systems.
• Can de-embed audio without being connected to an HDMI display.
• Supports embedding and de-embedding at the same time.
• Controlled through simple DIP switch configuration.
Warranty
Limited Warranty: 3 Year
About Black Box
For over forty years, Black Box has been a world-leading provider of premier IT infrastructure solutions. Today, we continue to design and manufacture award-winning products for Pro AV, KVM, cabling and networking known for their advanced functionality, flawless performance, outstanding reliability and fail-safe security. Our solutions are used every day in government, education, commercial enterprises and any other organization that requires the utmost quality and performance from their IT infrastructure.
On top of creating industry-leading products, Black Box demonstrates every day a complete commitment to providing our customers with the best technical support and service in the industry. Our award-winning, dedicated support staff works around the clock to ensure our customers’ systems are always up and running optimally. They are truly as important to the successful IT, communications and business operations of our customers as the powerful products and solutions we deliver.
Highlights
2-in-1 solution.
Add audio to a video signal or extract audio from an HDMI signal with embedded audio.
Support HDMI 2.0 with 4K60 video.
HDCP 2.2 compliant.
Supports audio embedding or extraction via analog stereo or digital TOSLINK.
Supports ARC audio extraction via TOSLINK.
Supports HDMI, 3.5-mm analog audio, and TOSLINK optical audio inputs and outputs.
Supports resolutions of up to 4K at 60 Hz in 4:4:4 color.
Embeds audio from either a 3.5-mm or optical source to an HDMI or DVI-D signal.
Create audio channels where there was not an existing one.
Specifications
General Information
Manufacturer
Black Box Corporation
Manufacturer Part Number
AEMEX-HDMI-R2
Brand Name
Black Box
Product Name
Audio Embedder/De-embedder - HDMI 2.0
Packaged Quantity
1
Product Type
Signal Extractor
Interfaces/Ports
USB
Yes
HDMI
Yes
Audio Line In
Yes
Audio Line Out
Yes
Physical Characteristics
Form Factor
Mountable
Height
1"
Width
3.7"
Depth
2.6"
Weight (Approximate)
0.57 lb
Technical Information
Functions
Audio Embedding, Audio De-embedding
Warranty
Limited Warranty
3 Year
Miscellaneous
Package Contents
Audio Embedder/De-embedder - HDMI 2.0
1 x 5-Volt, 4-Amp Power Supply with Adapter Clips
2 x Mounting Screws
User Manual
Country of Origin
Taiwan
TAA Compliant
Yes
Environmentally Friendly
Yes
Environmental Compliance
Restriction of Hazardous Substances (RoHS) 2, Waste Electrical and Electronic Equipment Directive (WEEE)
