Genuine AtlasIED through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
HPA1302
Category
A/V Receivers & Amplifiers
Overview
The AtlasIED High Power Amplifier HPA Series model HPA1302 has been designed to be used in both commercial 70V/100V distributed systems and professional applications that require amplifiers to handle 8? and 4? loads.
The HPA Series features Generation II Class D Output topology that provides superior efficiency with the sound quality of a Class AB amplifier. The power supply is a switch mode wide range design that maintains a stable output during fluctuating power conditions. The power supply and output stage collectively are designed to deliver exceptional dynamic high output voltage and current to virtually any loudspeaker load.
The HPA Series features front panel stepped level controls with a security cover, remote turn on, balanced line inputs with sensitivity settings, fault reporting and an accessory card slot for an optional Dante two-channel digital audio interface. Cooling is not an issue because of the unique output stage low resistance direct couple thermal transfer design. HPA also is energy efficient and meets Energy Star 1W standby mode standards.
Whether the application is a large distributed constant voltage sound system or a high SPL sound reinforcement system, the AtlasIED HPA Series is the answer for high power/cost effective reliable amplification requirements.
Warranty
Limited Warranty: 3 Year
Highlights
4?, 8?, 70.7V, & 100V Operation
Balanced Inputs Euro Block Phoenix Style Connector
Accessory Card Slot for Optional Dante Digital Network Audio Card
Short-Circuit, Temperature, and DC Offset Protection
Auto Sensing 100V-240V~ AC Mains Power Supply
Stepped Attenuators with Security Covers
Specifications
Audio
Audio Channels
2
RMS Output Power
1300 W
General Information
Manufacturer
AtlasIED
Manufacturer Part Number
HPA1302
Brand Name
AtlasIED
Product Series
HPA
Product Model
HPA1302
Product Name
Dual-Channel, 1300-Watt Commercial Amplifier
Product Type
Amplifier
Physical Characteristics
Product Color
Black
Height
3.5"
Width
19"
Depth
9.3"
Weight (Approximate)
15.40 lb
Power Description
Operating Power Consumption
1000 W
Technical Information
Minimum Frequency Response
20 Hz
Maximum Frequency Response
20 kHz
Impedance
4 Ohm
Classification
D
Warranty
Limited Warranty
3 Year
Miscellaneous
Energy Star
Yes
Environmentally Friendly
Yes
Environmental Compliance
Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
