DIN Rail Mountable - 120 V AC, 230 V AC Input - 48 V DC Output - 480 W - Active PFC - 94% Efficiency
SKU
Category
Power Supplies
$452.05
Back-ordered
Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Oct 6 and Nov 10, then process your delivery right after.
Genuine Allied Telesis through authorized distribution — NDAA §889 screened before checkout. TAA verified on request.
SKU
Category
Power Supplies
Overview
IE048 Series Industrial AC/DC Power Supply, 48VDC Output
The IE048 industrial power supplies are functional accessories for Allied Telesis products. They are ideal for Smart Cities, Industrial Ethernet, Transportation or any application requiring systems that function in harsh environments with extended operating temperatures.
Overview
The IE048 Series power supplies deliver reliable 48VDC output voltage. They are fully tested and validated to operate with Allied Telesis Industrial products.
Housed in a compact metal case with DIN rail clip, the IE048 features mechanical robustness, electromagnetic compatibility and enhanced thermal characteristics, making it ideal for exposed areas and harsh environments.
Highly efficient and stable output power provides the capability to support 150% of peak load. The nominal output voltage of 48VDC can be adjusted to match application requirements.
The AC/DC rectifier operates over the full range of AC input voltage to fit worldwide power grids. The included active Power Factor Correction circuit (PFC) reduces energy costs by eliminating reactive power and harmonics from power lines.
As well as providing efficiency, the PFC complies with international regulations. It establishes limits on the harmonic currents that can appear on an AC main line.
Warranty
Limited Warranty: 5 Year
Highlights
Electromagnetic immunity for industrial environments
Highly efficient
Active PFC
Stable output power with 150% peak current capability
Wide input voltage range
Protections: peak-current, over-current and over-temperature
Remote ON/OFF
Output power confirmation relay (DC_OK)
Extended operating temperature range
Air convention cooling
Metal case
DIN rail mount
Conformal coating
Warranty period: 5 years
Specifications
Environmental Conditions
Minimum Operating Temperature
-13°F (-25°C)
Maximum Operating Temperature
158°F (70°C)
General Information
Manufacturer
Allied Telesis, Inc
Manufacturer Part Number
AT-IE048-480/C-20
Brand Name
Allied Telesis
Product Series
IE048
Product Name
480W Power Supply
Product Type
Power Supply
Physical Characteristics
Form Factor
DIN Rail Mountable
Height
4.9"
Width
2.8"
Depth
4.6"
Weight (Approximate)
2.65 lb
Power Description
Input Voltage
120 V AC, 230 V AC
Output Voltage
48 V DC
Output Current
10 A, 15 A
Output Power
480 W
Technical Information
Efficiency
94%
Power Factor Correction (PFC)
Active
Protection Type
Over Current, Over Voltage, Over Temperature
Warranty
Limited Warranty
5 Year
Miscellaneous
Environmental Compliance
Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
