Overview
Thank you for buying this NetBotz CCTV Adapter Pod 120. Designed for use with NetBotz 500 and 420 appliances and a single closed circuit television (CCTV) or other video source, the CCTV Adapter Pod accepts multi format S-Video and Composite Video and features DIN, BNC and RCA input jacks. This pod also features a USB port that enables the pod to be tethered to the base station using a standard USB cable. Using the CCTV Adapter Pod, your analog video source is digitally converted and integrated with the NetBotz physical security solution. Streaming audio (using the pod's integrated microphone or an external microphone connected to the pod) is also available.
Warranty
Limited Warranty: 2 Year
Highlights
- Converts analog video source to digital
- The monitoring appliance can then utilize digital images for motion sensing, alert image captures, etc.
- CCTV Pod provides images up to 640x480 resolution, 24-bit color, and up to 30 fps
- Color & resolution may be limited by CCTV video source
- CCTV camera connects to either BNC, RCA, or S-Video input on CCTV Adapter Pod
- 1 CCTV camera per adapter pod
- NTSC, PAL, or SECAM video source input format
- Distance between Pod and WB500 base station can be extended with USB extension cables, or CAT5 or Fiber Pod Extenders
- External jacks for microphone (internal mike also), speaker, door switch sensor
Specifications
| Package Contents |
|
|---|---|
| Product Type | CCTV Adapter Pod |
| Compatibility | CCTV |
| Manufacturer Part Number | NBPD0123 |
| Limited Warranty | 2 Year |
| Weight (Approximate) | 8 oz |
| Manufacturer | Schneider Electric SA |
| Product Model | 120 |
| Product Name | 120 CCTV Adapter Pod |
| Brand Name | APC by Schneider Electric |
| Country of Origin | Mexico |
| Height | 2.7" |
| Width | 4.3" |
| Depth | 1.1" |
| Environmentally Friendly | Yes |
| Product Color | Black |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
