4G - LTE Cat 4, DC-HSPA+, WCDMA, HSPA+, UMTS, LTE - Single Band - 2.40 GHz ISM Band - 37.50 GB/s Wireless Speed - 1 x Network Port - 1 x Broadband Port - USB - Gigabit Ethernet - VPN Supported - DIN Rail Mountable, Portable
Genuine ERICSSON through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
TBA3-600C150M-NN
Category
Wireless Routers
Overview
The Cradlepoint IBR600C Series Router for IoT networks is a semi-ruggedized, cloud-managed LTE router, built for IoT and M2M applications. They provide a resilient, LTE connection ideal for use in high-availability, portable, or fixed uses. The IBR600C Series is available with IoT NetCloud Service Plans, which provide features optimized for each unique deployment.
Semi-Ruggedized IoT Solution
When coupled with the NetCloud IoT service plan, the IBR600C router provides a compact semi-ruggedized 4G LTE router solution for connecting and protecting IoT devices at scale. It is ideal for use in high-availability portable or fixed applications such as surveillance cameras, digital signs, oil and gas monitoring, and parallel networking. With an extensive list of features, it can be confidently deployed in the field, in buildings, or in embedded systems to deliver complete visibility, security, and control of connected devices anywhere.
Robust Cloud Managed IoT Solution
For organizations requiring robust connectivity for IoT networks - with installed routers numbering from hundreds to many thousands - Cradlepoint's NetCloud Service for IoT with the IBR600C router provides a comprehensive cloud managed network solution. When coupled with advanced IoT features, it provides troubleshooting and diagnostics with in-band and out-of-band management, extensive analytics and insights, and extensibility and integrations such as Microsoft Azure IoT Central. Cradlepoint's NetCloud-managed IoT endpoints can be rapidly deployed and easily scaled to accommodate the diverse requirements of organizations.
Highlights
Define policies through centralized, cloud-based management for easy deployment at scale.
Gain fast, reliable connectivity with an embedded Cat 4 modem with dual SIM support.
Expand working radius and IoT connectivity with secure, enterprise class Wi-Fi.
Provide a semi-ruggedized, portable solution capable of enduring harsh environments.
Utilize Configurable GPIO ports and NetCloud Integrations for IoT applications.
Customize and extend NetCloud Service functionality with NetCloud SDK and API.
Specifications
Package Contents
IBR600C 150M-D Modem/Wireless Router
Power Supply, 12V Small 2x2 1.5 meters
2 x Cellular Antenna, 600 MHz - 6 GHz, SMA Black Mini
2 x Wi-Fi Antenna, Charcoal, Dual-Band 2.4/5 GHz, RPSMA
Product Type
Modem/Wireless Router
Manufacturer Part Number
TBA3-600C150M-NN
Limited Warranty
Lifetime
VPN Supported
Yes
Weight (Approximate)
14.11 oz
Network Band
Single Band
Form Factor
DIN Rail Mountable, Portable
Manufacturer
ERICSSON
Product Model
150M-D
Product Name
IBR600C 150M-D Modem/Wireless Router
Product Series
IBR600C
Brand Name
CradlePoint
Height
1.2"
Width
4.6"
Depth
4.5"
Broadband Transmission Technology
Ethernet, Cellular
Wireless LAN Standard
IEEE 802.11b/g/n
ISM Band
Yes
ISM Maximum Frequency
2.40 GHz
Ethernet Technology
Gigabit Ethernet
USB
Yes
Number of Network (RJ-45) Ports
1
Cellular Data Connectivity Technology
LTE Cat 4, DC-HSPA+, WCDMA, HSPA+, UMTS, LTE
Multi-SIM Supported
Yes
Cellular Generation
4G
Number of Broadband (RJ-45) Ports
1
Total Number of Network Ports
2
Number of SIM Card Supported
2
SIM Size Supported
Mini
Total Wireless Transmission Speed
37.50 GB/s
Wi-Fi Generation
Wi-Fi 4
Environmental Compliance
Waste Electrical and Electronic Equipment Directive (WEEE), Restriction of Hazardous Substances (RoHS), Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
