Eaton Tripp Lite Series SmartRack Copper Bus Grounding Bar for 24U and 25U Racks

0.6? Width

SKU: SRGROUND25
Category: Shelf Mounting & Ground Kits

MSRP$220.03

$143.51

Save 35%

In stock: 211

Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU: SRGROUND25
Category: Shelf Mounting & Ground Kits

Overview

Provides Convenient Ground Contact for Your Rack-Mounted Equipment

This SmartRack® grounding bar is a thin strip of heavy-gauge solid copper that attaches to any EIA-standard 24U or 25U rack enclosure or open frame rack. Every other U space has a drilled and tapped hole to allow a ground wire jumper to be installed, providing convenient ground contact for standard rack equipment. The jumper then bridges to individual rack components, with grounding straps, allowing a direct path to ground, rather than going through surrounding equipment.

Easy to Install with All Hardware Included

You can mount the SRGROUND25 in any EIA-standard 24U or 25U rack enclosure or open frame rack. Either screw it into a rack enclosure using the included mounting hardware, or install it in an open frame rack with the included toolless mounting buttons. This copper grounding bar is ideal for large data centers that contain ground-sensitive equipment.

Typical Applications

Provides convenient ground contact for standard rack-mount equipment in a 24U or 25U rack

Warranty

Limited Warranty: 5 Year

About Eaton

Eaton is an intelligent power management company dedicated to improving the quality of life and protecting the environment for people everywhere. We are guided by our commitment to do business right, to operate sustainably and to help our customers manage power ─ today and well into the future. By capitalizing on the global growth trends of electrification and digitalization, we're accelerating the planet's transition to renewable energy and helping to solve the world's most urgent power management challenges.

Highlights

Copper grounding bar provides ground contact for your rack-mount equipment
Installs in your 24U or 25U enclosure or open frame rack with included hardware
Recommended for large data centers that have ground-sensitive equipment
Heavy-gauge copper construction with drilled and tapped hole in every other U space
5-year limited warranty

Specifications

Package Contents	Copper Bus Grounding Bar for 24U and 25U Racks 2 x Mounting Buttons 13 x Grounding Straps 2 x M4 Self-tapping Screws 13 x M4 Screws 13 x Washers 2 x Cage Nuts 2 x M6 x 12 Screws Owner's Manual
Product Type	Grounding Bar
Manufacturer Part Number	SRGROUND25
Limited Warranty	5 Year
Weight (Approximate)	3 lb
Manufacturer	Eaton Corporation
Product Name	Copper Bus Grounding Bar for 24U and 25U Racks
Brand Name	Tripp Lite series
Country of Origin	China
Height	45.2"
Width	0.6"
Depth	0.3"
Environmentally Friendly	Yes
Product Material	Copper
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
