Our high performance HDMI 1x2 Splitter distributes one HDMI input to two simultaneous HDMI outputs. The HDMI Splitter also supports HDCP 2.2, 3D, 12-bit Deep Color as well as High Definition Lossless Audio. With EDID selections, users can choose between TV (downstream) or STD (fixed) settings. The Splitter supports video signals up to Ultra-high-definition UHD 4K@60Hz (YUV444) , and is capable of receiving and transmitting up to 18Gbps of bandwidth with no data loss. In addition, the HDMI 1x2 splitter has a slim chassis design with an enclosure made of durable metal.
Comprehensive's HDMI 1x2 splitter is perfect for huddle spaces, classrooms, collaboration, conference Rooms, showroom displays, lecture halls, retail sales displays and anywhere in between. All components are RoHS Compliant and come with a 3 Year Hassle-Free Warranty.
Why choose Comprehensive?
Since 1974 Comprehensive has been the Pro A/V and IT industry standard for professional connectivity performance, reliability and value. That's why millions of Comprehensive connectivity products are in use at stadiums, in broadcast and recording studios, stages, boardrooms, classrooms, government installations and living rooms around the world. At Comprehensive, we stand for one thing above all else - exceeding our customer's expectations every time with new and innovative high value products and the same old-fashioned customer service that built our business. We know in today's busy world, you have more important things to worry about than connectivity products. That is why we strive every day to make your life, and connectivity a little easier.
Warranty
Limited Warranty: 3 Year
Highlights
Distribute one HDMI input to two simultaneous HDMI outputs
Supports Ultra-HD resolutions up to 4k2k@30Hz with 24bit RGB/YcbCR 4:4:4/YCBCR 4:2:2,and up to
4k2k@60Hz with 12bit YCBCR 4:4:4
, high resolution VESA mode video format up to QSXGA@60Hz
12-bit Deep Full HD, Full 3D, HDR
Wide Frequency Range: 25MHz - 600MHz
Compliant with HDMI 2.0a, HDMI 1.4b (1080p@60Hz) and DVI 1.0 specification
Integrated HDCP 1.4 and HDCP 2.2 decryption/encryption engines
LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio support, and HD losless audio
Smart EDID control
Durable Metal Enclosure
3 Year Warranty
Specifications
General Information
Manufacturer
Comprehensive Connectivity Company
Manufacturer Part Number
CDA-HD12018G
Brand Name
Comprehensive
Product Name
1x2 HDMI Full UHD 4K60 18Gb Splitter (YUV:444)
Packaged Quantity
1
Product Condition
New
Product Type
Signal Splitter
Interfaces/Ports
HDMI In
Yes
HDMI Out
Yes
Number of HDMI Inputs
1
Number of HDMI Outputs
2
Physical Characteristics
Product Material
Metal
Height
0.7"
Width
2.2"
Depth
3.8"
Weight (Approximate)
3.53 oz
Power Description
Input Voltage
5 V DC
Technical Information
Minimum Frequency
25 Hz
Maximum Frequency
600 MHz
Video
Maximum Video Resolution
4096 x 2160
Warranty
Limited Warranty
3 Year
Miscellaneous
Package Contents
1x2 HDMI Full UHD 4K60 18Gb Splitter (YUV:444)
1 x 5V/1A DC Power Adaptor (US, CE/FCC/UL certified)
