Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Sep 29 and Nov 3, then process your delivery right after.
Genuine Advantech through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
Category
Routers & Gateways
Overview
The ICR-4401 is a High-Speed Wired Router & Powerful Edge Computing Gateway. This router is an ideal solution for critical industrial systems and IIoT. It serves well also for connection of traffic and security camera systems, individual computers, LAN networks and various self-service terminals.
The new router platform "v4" provides intelligence at the network edge with an extremely powerful Cortex A72 CPU at 1200 MHz, 4 GB eMMC memory, 4 MB flash memory, and 1024 MB RAM. The focus on high security underlines using TPM 2.0, and the Tamper Button that ensures safe use in industrial systems. The ICR-4401 is powered by the ICR-OS Linux operating system that provides a wide range of enhanced networking features. A secure Web interface allows users to configure and manage routers from remote locations.
The router supports multiple configuration profiles, automatic firmware updates, etc. The router can be used as a powerful edge computing gateway because of the support of many ways of software customization. Users may insert Linux scripts and add new features by additional applications called Router Apps (User Modules).
There is an existing free library of Router Apps or the user may create own app using Advantech SDK. The gateway can easily run applications like Node-RED or Docker that open the way to a multi-container world.
The ICR-4401 is designed and manufactured for use in tough environmental conditions. Specifications include a wide operating temperature ranges from -40 to +75 °C. It accepts input voltage range from 9 V DC to 48 V DC and is equipped with sleep mode for reducing electrical consumption.
As a standard, ICR-4401 is equipped with five Ethernet 10/100/1000 Mbps (1× independent and 4× switch), SFP cage (independent port), one USB host 2.0, microSD reader, serial lines RS232 and RS485, CAN Bus, two binary inputs, and two binary outputs. ICR-4401 has two mPCIe connectors that can be used for two WiFi modules. The router is supplied in a robust metal casing for a wall mount (DIN mount is optional).
To streamline management and deployment of the ICR-4401 router family can be easily managed using a comprehensive cloud-based tool WebAccess/DMP. This software tool enables centralized management, provisioning, and monitoring of multiple routers, simplifying the process of scaling and maintaining a network infrastructure or centralize management of VPN connections.
Warranty
Limited Warranty: 36 Month
Highlights
Quad-core CPU with 1 GB RAM
5× Gigabit Ethernet (Optional 4× POE+ PSE)
SFP Connector for SFP modules up to 10 Gbps
TPM 2.0
RS232, RS485, CAN BUS, 2× DI, 2× DO, USB Host
Micro SD Card
Robust metal cover with wall and DIN mount options
Wide operational temperature range
Optional Dual-Band Wi-Fi
Specifications
General Information
Manufacturer
Advantech Co., Ltd
Manufacturer Part Number
ICR-4401
Brand Name
Advantech
Product Model
ICR-4401
Product Name
ICR-4401 Wireless Router
Product Type
Router
Interfaces/Ports
Total Number of Ports
5
USB Standard
USB 2.0
Number of Network (RJ-45) Ports
4
Number of WAN Ports
1
Memory
Standard Memory
4 GB
Network & Communication
Ethernet Technology
10 Gigabit Ethernet
Networking Standards
IEEE 802.3
Physical Characteristics
Form Factor
Wall Mountable, DIN Rail
Height
1.9"
Width
7.7"
Depth
4.3"
Weight (Approximate)
2.98 lb
Power Description
Power Consumption
4.20 W
Warranty
Limited Warranty
36 Month
I/O Expansions
Total Number of Expansion Slots
1
Expansion Slot Type
SFP (mini-GBIC)
Miscellaneous
Package Contents
ICR-4401 Wireless Router
2-pin PWR Connector
14-pin Serial / IO Connector
Wall Mount Kit
Environmental Compliance
Restriction of Hazardous Substances (RoHS) 3, Waste Electrical and Electronic Equipment Directive (WEEE), Registration, Evaluation, Authorization and Restriction of Chemicals (REACH), Restriction of Hazardous Substances (RoHS)
