Advantech 4U Storage Chassis for ATX/EATX Serverboard with 24 Hot-swap Drive Bays
Advantech

Advantech 4U Storage Chassis for ATX/EATX Serverboard with 24 Hot-swap Drive Bays

Rack-mountable - 4U - 26 x Bay - 2 x 550 W - Power Supply Installed - ATX, EATX, Micro ATX Motherboard Supported - 2 x External 2.5" Bay - 24 x External 2.5"/3.5" Bay(s) - 6x Slot(s) - 2 x USB(s)

SKU
HPC-8424SA-R5A1E
Category
Computer Cases

$2,159.93

Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Advantech through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
HPC-8424SA-R5A1E
Category
Computer Cases

Highlights

  • 4U rackmount chassis supports EATX/ATX/uATX motherboard
  • 24-bay hot-swappable 3.5"/2.5" SAS 12Gb/s drives or SATA 6Gb/s drives
  • 4 x NVMe drives supported via an optional riser card
  • Support 2 hot-swappable 2.5" drive bays at the rear
  • Supports 80+ redundant power supply

Specifications

Package Contents
  • 4U Storage Chassis for ATX/EATX Serverboard with 24 Hot-swap Drive Bays
  • 1 x Slide Rail Kit
Product TypeServer Case
Manufacturer Part NumberHPC-8424SA-R5A1E
Motherboard SupportedATX, EATX, Micro ATX
Weight (Approximate)68.34 lb
Form FactorRack-mountable
ManufacturerAdvantech Co., Ltd
Product ModelHPC-8424
Product Name4U Storage Chassis for ATX/EATX Serverboard with 24 Hot-swap Drive Bays
Brand NameAdvantech
Country of OriginChina
Height6.9"
Width17.2"
Depth21.3"
Number of Fans Installed4
Number of External 2.5" Bays2
Compatible Rack Unit4U
Number of Power Supplies Supported2
Number of Power Supplies Installed2
Power Supply Wattage550 W
Number of Total Expansion Bays26
Total Number of USB Ports2
Installed Fan Size3.15"
Total Number of Expansion Slots6
Power Supply InstalledYes
Number of External 2.5"/3.5" Bays24
