Genuine Netgear through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
GS524PP-100NAS
Category
Switches & Bridges
Overview
GS516PP and GS524PP Unmanaged Gigabit Ethernet PoE+ Switches
The GS516PP 16-port High-power PoE+ Gigabit Ethernet Unmanaged Switch and the GS524PP 24-port High-power PoE+ Gigabit Ethernet Unmanaged Switch join the NETGEAR Unmanaged switch family, adding full 16 and 24 port PoE+ support for flexible deployment of modern high-power PoE devices. Companies can now deploy denser PoE+ devices connected to a single switch instead of multiples with a total PoE power budget of 260W (GS516PP) and 300W (GS524PP). The quiet design makes the GS516PP and GS524PP ideal for any home or business environment.
GS516UP and GS524UP Unmanaged Gigabit Ethernet High-power PoE+ switches with PoE++ ports
NETGEAR brings even larger PoE budgets on Unmanaged switches with Ultra60 PoE++ technology with two new 16- Port (GS516UP) and 24-port (GS524UP) Unmanaged Switches, ideal for powerful PoE+/PoE++ installations with impressive PoE budgets up to 380W and 480W, a compact size, plug-and-play installation, and reliable performance at affordable prices.
These switches can support all types of PoE installation with larger PoE budgets and ports that provide PoE+ and PoE++ power for up to 60W per port.
Standardized to IEEEE 802.3bt, the Ultra60 PoE++ switches can deliver up to 60W of power per port, allowing the connections of higher power required devices, such as high performance 802.11AX wireless access points, PTZ and 4K IP surveillance cameras, PoE lighting, PoE-powered audio speakers, as well as other high-powered devices. The GS516UP and GS524UP has a PoE mode used to enable pre-802.bt compatibility for pre-bt devices that were created before 802.3bt Standard was ratified.
Highlights
High-power PoE with impressive PoE budgets for all types of PoE installations
Simple set up with no software or configuration needed
Per port LEDs for port activity and speed
Energy efficient technology for power savings
Auto-negotiation for automatic connection at the highest common speed between switch and an end device
16 or 24 auto-sensing 10/100/1000 Mbps Gigabit Ethernet ports with up to 32 or 48Gb non-blocking switching
Auto-MDI/MDIX eliminates the need for crossover cables
Small, sturdy desktop metal case and quiet operation
Ideal for small and medium offices
Non-blocking switching architecture for maximum throughput at wire speed
Specifications
Package Contents
GS524PP Ethernet Switch
Power Cord
Rackmount Kit
Desktop Rubber Feet
Insight Registration Flyer
Installation Guide
Product Type
Ethernet Switch
Manufacturer Part Number
GS524PP-100NAS
Power Source
Power Supply, PoE
Limited Warranty
Lifetime
Layer Supported
2
Weight (Approximate)
6.37 lb
Form Factor
Desktop, Rack-mountable
Manufacturer
Netgear, Inc
Product Model
GS524PP
Product Name
GS524PP Ethernet Switch
Network Technology
10/100/1000Base-T
Power Consumption
359.50 W
Brand Name
Netgear
Country of Origin
Thailand
Height
1.7"
Width
15.4"
Depth
8.7"
Manageable
No
Environmentally Friendly
Yes
Ethernet Technology
Gigabit Ethernet
Uplink Port
Yes
Media Type Supported
Twisted Pair
Total Number of Network Ports
24
PoE (RJ-45) Port
Yes
Port/Expansion Slot Details
24 x Gigabit Ethernet PoE+
PoE Budget
300 W
Energy Efficiency Compliance
Energy-related Products Directive (ErP)
Environmental Compliance
Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE), Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
