Lenovo
Lenovo ThinkSystem ST250 V3 7DCEA02FNA Tower Server - 1 x Intel Xeon E-2434 3.40 GHz - 16 GB RAM - 12Gb/s SAS Controller
Intel C266 Chip - 1 Processor Support - 128 GB RAM Support - TruDDR5 - 0, 1, 5, 10, JBOD RAID Levels - Matrox Up to 16 MB Graphic Card - Gigabit Ethernet - 6 x Total Bay(s) - 4 x LFF Bay(s) - Hot Swappable Bays - 1 x 300 W
- SKU
- 7DCEA02FNA
- Category
- Servers
$2,353.14
Back ordered
Back ordered — ships when restocked.
Genuine Lenovo through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- 7DCEA02FNA
- Category
- Servers
Overview
The Lenovo ThinkSystem ST250 V3 is a mainstream 1-socket tower server that also be rack mounted as a rack server. It is ideal for small-to-medium businesses, remote offices, branch offices, banking and public sector. The server supports the new Intel Xeon E-2400 Series processors, formerly codenamed "Raptor Lake".
Highlights
- 1 processors supported for optimal performance and maximum reliability in mission-critical server environments
- With 16 GB memory, improve system performance and reduce processing delays
- 1 x 300 W power supply unit (PSU) included for dependable performance and redundancy in enterprise setups
- Intel Xeon 3.40 GHz processor provides enterprise-grade performance with built-in security and remote management capabilities
- Tower form factor is cost-effective and highly configurable, making it suitable for growing businesses with evolving needs
- RAID enhances reliability and speed through RAID levels (0, 1, 5, 10, JBOD), balancing data protection with optimized performance
- TruDDR5 memory technology enables efficient data movement across CPU cycles, improving throughput for demanding server workloads
- Gigabit Ethernet port offers ultra-fast network speeds, supporting modern workloads and reducing bottlenecks in data flow
- 2 Network (RJ-45) Ports eliminate the need for additional wiring, streamlining deployment and reducing installation costs
- 7 USB ports allow quick, high-speed data transfer for your convenience, making file sharing and backups effortless
Specifications
| Additional Warranty Information | Three-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD). |
|---|---|
| Package Contents |
|
| Product Type | Server |
| Cache | 8 MB |
| Error Checking | ECC |
| Input Voltage | 120 V AC, 230 V AC |
| Manufacturer Part Number | 7DCEA02FNA |
| Maximum Memory Supported | 128 GB |
| Signal Processing | Unregistered (Unbuffered) |
| Limited Warranty | 3 Year |
| Standard Memory | 16 GB |
| Weight (Approximate) | 52.80 lb |
| Form Factor | Tower |
| Manufacturer | Lenovo Group Limited |
| Product Model | 7DCEA02FNA |
| Product Name | ThinkSystem ST250 V3 7DCEA02FNA Server |
| Processor Speed | 3.40 GHz |
| Processor Type | Xeon |
| Product Line | ThinkSystem |
| RAID Levels | 0, 1, 5, 10, JBOD |
| Security Features |
|
| Controller Type | 12Gb/s SAS |
| Product Series | ST250 V3 |
| Brand Name | Lenovo |
| Plug/Connector Type | C13 |
| Operating System Supported | Windows Server 2022, Red Hat Enterprise Linux 8.8, Red Hat Enterprise Linux 9.2, Red Hat Enterprise Linux 8.9, Red Hat Enterprise Linux 9.3, SUSE Linux Enterprise Server 15 SP5, Ubuntu 22.04 LTS x64, Red Hat Enterprise Linux 8.10, Red Hat Enterprise Linux 9.4, SUSE Linux Enterprise Server 15 SP6, Ubuntu 24.04 LTS x64 |
| Memory Technology | TruDDR5 |
| Processor Model | E-2434 |
| Height | 17.5" |
| Width | 6.9" |
| Depth | 22.8" |
| Processor Core | Quad-core (4 Core) |
| Environmentally Friendly | Yes |
| Environmental Certification | GREENGUARD, China Environmental Labeling Program (CELP), Electronic Product Environmental Assessment Tool Bronze (EPEAT Bronze) |
| Processor Manufacturer | Intel |
| Number of External 5.25" Bays | 2 |
| Chipset Manufacturer | Intel |
| Chipset Model | C266 |
| Graphics Controller Manufacturer | Matrox |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 1 |
| Graphics Memory Capacity | 16 MB |
| Hot Swappable Power Supply | Yes |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| RAID Supported | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Number of Total Expansion Bays | 6 |
| Number of 3.5" Bays | 4 |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Network (RJ-45) | Yes |
| Maximum Power Supply Wattage | 300 W |
| Remote Management | Yes |
| Total Number of USB Ports | 7 |
| Number of USB 2.0 Ports | 1 |
| Total Number of Expansion Slots | 4 |
| Energy Star | Yes |
| Number of Occupied Memory Slots | 1 |
| Hot Swappable Bays | Yes |
| Memory Clock Speed | 4.80 GHz |
| Controller Model | 5350-8i |
| Number of LFF Bays | 4 |
| PCI Express Details | 4x PCIe slots (x4, x16, x4, x4) |
| Remote Management Controller | XClarity Controller2 (XCC2) Standard |
| Total Number of Memory Slots | 4 |
| Energy Efficiency Certification | China Energy Conservation Program (CECP), ENERGY STAR 4.0 |
| Energy Efficiency Compliance | Energy-related Products Directive Lot 9 (ErP Lot 9) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
