StarTech 1-Port PCI Express Serial Card, PCIe to RS232 (DB9) Interface Card, 16C1050 UART, COM Retention, Low Profile, Win/Linux, TAA
Connect a serial RS232 (DB9) device using this PC Serial Card. Supports 16C1050 UART. LED lights to monitor activity on the PCI express DB9 card - The UART PCIe card supplies 5/12V over pin 9. Continue using legacy hardware with this RS232 PCIe card
Genuine StarTech.com through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
11050-PC-SERIAL-CARD
Category
Serial/Parallel Adapters
Overview
Add serial communication support to your desktop computer or Small Form Factor (SFF) system, using this serial card. RS-232 (DB9) support enables control and communication with a serial peripheral device.
Legacy Connectivity
Install this card to enable the continued use of legacy serial devices, preventing down time and avoiding costly upgrades. The PCIe serial card is ideal for system upgrades in a wide range of applications for logistics, manufacturing, and freight sectors, and the IT industry, such as POS equipment, security systems, A/V installations, and more.
Connect with Ease
The RS-232 card features 16C1050 UART support, 256-byte FIFO (transmit/receive), bi-directional speeds up to 921.6 Kbps, low-profile bracket is included for SFF systems, and serial port LED status lights. In addition, it supports Windows and Linux systems for maximum compatibility.
11050-PC-SERIAL-CARD is backed for 2-years by StarTech.com, including free lifetime 24/5 multi-lingual technical assistance.
More from the Manufacturer
More from the Manufacturer
Highlights
PCIE TO SERIAL: Connect a serial RS232 (DB9) devices to a computer with this PC serial card. Features support for high performance 16C1050 UART. Monitor activity with the built-in LED status lights on the PCI express DB9 card
DEVICE COMPATIBILITY: Use this serial interface card to connect barcode readers/scanners, receipt printers, scales, PLCs, medical devices, etc. The UART PCIe card supplies 5V or 12V power over pin 9. Low-profile bracket is included
APPLICATIONS: This card is ideal for IT applications such as server rooms, industrial control/automation, logistics, and laboratories. Continue using legacy hardware with this RS232 PCIe card. DB9 port accepts screw locking serial cables
PC SERIAL CARD SPECS: 16C1050 UART | Max Baud 921.6 Kbps | 256 Byte FIFO | COM Retention | Supports Windows and Linux | Asix AX99100 Chipset | Odd/Even/Mark/Space/None Parity Modes | 5/6/7/8/9 Data Bits | PCIe 2.0 x1 | Low-profile Bracket Included
THE IT PRO'S CHOICE: Designed and built for IT Professionals, this PCIe to RS232 card is backed for 2-years, including free lifetime 24/5 multi-lingual technical assistance
Specifications
Additional Warranty Information
2-years by StarTech.com, including free lifetime 24/5 multi-lingual technical assistance.
Package Contents
PCIe Serial Card
1 x Low-Profile Bracket
1 x Quick-Start Guide
Host Interface
PCI Express x1
Product Type
Serial Adapter
Manufacturer Part Number
11050-PC-SERIAL-CARD
Platform Supported
PC, Linux
Limited Warranty
2 Year
Weight (Approximate)
0 oz
Form Factor
Plug-in Card
Manufacturer
StarTech.com
Product Name
PCIe Serial Card
Brand Name
StarTech.com
Country of Origin
Taiwan
Height
0.7"
Width
2.6"
Depth
2.6"
Environmentally Friendly
Yes
Card Height
Low-profile
Number of Serial Ports (External)
1
Environmental Compliance
Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
