Emerald® DESKVUE PE IP Multi-Source Receiver - Quad-Monitor, 4K, DisplayPort, Audio, TAA
4 Computer(s) - 328.08 ft Range - 4K - 3840 x 2160 Maximum Video Resolution - 2 x Network (RJ-45) - 10 x USB - DisplayPort - 120 V AC, 230 V AC Input Voltage - Desktop - TAA Compliant
SKU
EMD5004PE-R
Category
KVM Consoles/Extenders
MSRP$7,884.09
$7,501.05
Save 5%
Back-ordered
Special order — estimated available by September 10, 2026.
Genuine Black Box through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
EMD5004PE-R
Category
KVM Consoles/Extenders
Overview
What Is Emerald DESKVUE?
Emerald DESKVUE is an operator workspace that connects to Emerald endpoints to bring multiple systems into a single, visual command environment. It allows users to view and control physical computers, virtual machines, and web-based systems at the same time without switching keyboards, sessions, or desks.
Fault-Tolerant by Design
DESKVUE operates within Emerald's resilient architecture, maintaining access and control even during network disruptions or component failures. Operators stay connected when continuity matters most.
Advanced Virtual Machine Access
DESKVUE provides direct access to virtual machines alongside physical systems in the same workspace. Operators can interact with multiple systems simultaneously, supporting collaboration and modern, centralized computing environments.
Flexible BYOD Workflows
DESKVUE supports secure access from Windows and macOS devices, enabling operators to work from shared desks, mobile stations, or remote locations without changing how systems are accessed.
Unified Visual Workspace
DESKVUE replaces traditional system switching with a single, intuitive canvas. Operators can view multiple systems across multiple monitors, reducing screen clutter and minimizing cognitive load and burn out.
Enterprise-Grade Security
DESKVUE inherits Emerald's built-in security, including encrypted connections and controlled user access, ensuring systems remain protected without slowing operators down.
Centralized Visual Command
DESKVUE allows operators to see and act across multiple systems at once. WebLink technology enables secure, browser-based access to web interfaces such as HMI and SCADA.
Warranty
Additional Warranty Information: <p>2 Years Double Diamond Warranty (Standard)</p>
Limited Warranty: 2 Year
Highlights
Best in Class Virtual Machine Integration
Fault Tolerant Architecture
Unified Platform Architecture
Complete BYOD Solution
Enterprise Level Security
Centralized Command and Control
Specifications
General Information
Manufacturer
Black Box Corporation
Manufacturer Part Number
EMD5004PE-R
Brand Name
Emerald®
Product Line
DESKVUE
Product Name
DESKVUE PE IP Multi-Source Receiver - Quad-Monitor, 4K, DisplayPort, Audio, TAA
Packaged Quantity
1
Product Type
KVM Extender Receiver
Interfaces/Ports
Network (RJ-45)
Yes
USB
Yes
DisplayPort
Yes
Number of Network (RJ-45) Ports
2
Number of USB Ports
10
Physical Characteristics
Form Factor
Desktop
Receiver Height
11.42"
Receiver Width
3.65"
Receiver Depth
11.53"
Receiver Weight (Approximate)
8.52 lb
Power Description
Input Voltage
120 V AC, 230 V AC
Input Voltage Range
100-240VAC
Technical Information
Connectivity Technology
Wired
Number of Computers Supported
4
Maximum Operating Distance
328.08 ft
Video
Graphic Mode
4K
Maximum Video Resolution
3840 x 2160
Warranty
Limited Warranty
2 Year
Additional Warranty Information
2 Years Double Diamond Warranty (Standard)
Miscellaneous
Package Contents
DESKVUE PE IP Multi-Source Receiver - Quad-Monitor, 4K, DisplayPort, Audio, TAA
4 x Mini-DP Connectors (Mini-DP to DP Adapters Included)
1 x Country Specific Power Cord
Environmental Compliance
Waste Electrical and Electronic Equipment Directive (WEEE)
