Genuine Advantech through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
AIM-68CT-C2103000
Category
Tablets
Overview
Advantech's Industrial Tablet PC family, PWS series, provide integrated mobile computing solutions and several rugged devices, including Semi-rugged Tablets and Rugged Tablets for Field Services. They are built with durability and stability; sustainable in the toughest environments. The entire series of rugged tablets are an ideal platform to capture, process, and transfer data according to specific business requirements. The business requirements include Field Services, manufacturing, warehousing, military, electronic flight bag in flight operation, factory maintenance, transportation, police, fire, and other emergency services. With Field Service tablets and Rugged Tablets, Advantech provides a mobile computing solutions and Industrial Tablet PC to enhance your logistics work flow.
Highlights
Intel® Atom? processor with support for Windows 10 IoT and Android 6.0
10.1" WUXGA full HD display with scratch-resistant Corning® Gorilla® Glass 3 and multi-touch PCAP control
WLAN, BT, NFC, 3G/4G LTE technologies for seamless communication
Optional extension modules such as 1D/2D barcode scanner, LAN+COM module, and UHF RFID reader module
Optional accessories include an active stylus pen, hand strap, shoulder strap, as well as vehicle, VESA, and office docking stations
Additional modules and accessories can be customized according to application requirements
Specifications
Aspect Ratio
16:10
Package Contents
10.1" Industrial Tablet with Intel Atom Processor
Standard Battery
1 x AC/DC Adapter
1 x 2-pin Power Cord (USA)
Product Type
Tablet
Manufacturer Part Number
AIM-68CT-C2103000
Screen Resolution
1920 x 1200
Standard Memory
4 GB
Weight (Approximate)
2.16 lb
Operating System
Windows 10 IoT Enterprise
Features
Gorilla Glass 3, Water Resistant
Focus Modes
Fixed Focus, Auto-focus
Form Factor
Slate
Manufacturer
Advantech Co., Ltd
Product Model
AIM-68
Product Name
10.1" Industrial Tablet with Intel Atom Processor
Processor Speed
1.60 GHz
Processor Type
Atom x7
Screen Size
10.1"
Sensor Type
Gyro Sensor, Accelerometer, Digital Compass, Ambient Light Sensor
Product Series
AIMx8
Brand Name
Advantech
Memory Technology
LPDDR3
Memory Card Supported
microSD
Processor Model
x7-Z8750
Country of Origin
Taiwan
Height
7.1"
Width
11"
Depth
0.7"
Processor Core
Quad-core (4 Core)
Environmentally Friendly
Yes
Flash Memory Capacity
64 GB
Bluetooth
Yes
Wireless LAN
Yes
WWAN Supported
Yes
Wireless LAN Standard
IEEE 802.11ac
GPS
Yes
Cellular Data Connectivity Technology
LTE
Cellular Generation
4G
Number of USB 3.0 Ports
1
Rear Camera
Yes
Rear Camera Resolution
5 Megapixel
Operating System Platform
Windows
Front Camera
Yes
Front Camera Resolution
2 Megapixel
Energy Star
Yes
Energy Efficiency Certification
ENERGY STAR 6.1
Environmental Compliance
Waste Electrical and Electronic Equipment Directive (WEEE), China Restriction of Hazardous Substances (China RoHS)
