TRENDnet Powerline 500 AV Nano Adapter Kit With Built-In Outlet, Power Outlet Pass-Through, Includes 2 x TPL-407E Adapters, Plug & Play, Ideal For Smart TVs, Gaming, White, TPL-407E2K

The Powerline 500 AV Adapter Kit with Built-In Outlet, model TPL-407E2K, uses existing electrical lines to create a high-speed network. Two adapters are needed to start a network. Connect one adapter to your router and plug another adapter into an outlet on your electrical system for instant high-speed network access. The compact form factor saves space and offers an additional electrical outlet.

• Includes two TPL-407E adapters; Two adapters are needed to start a network

• NDAA COMPLIANT: With our NDAA compliant Powerline Ethernet Adapters, you can plan and install networking solutions that Government customers demand today (U.S. and Canada Only)

• MANUFACTURER PROTECTION: We stand by the quality of our products.The TPL-407E2K Powerline 500 AV Adapter Kit with Built-In Outlet is backed and supported with 3 years of TRENDnet Manufacturer Protection.

• PLUG IN INSTALL: Simply plug in TRENDnet adapters! The encrypted Powerline signal auto-connects over an existing electrical system.

• BUILT-IN OUTLET: With so many devices needing power, you don't lose an outlet when plugged in. Plug the adapter into an outlet, then plug a power strip into the adapter.

• NETWORK STABILITY: Ultra-stable Powerline networking is preferred by internet service providers.

• CONNECTIVITY TECHNOLOGY: Ethernet; Noise Filter: Advanced electrical noise filter boosts performance

• EASY INSTALLATION: Simply plug in the adapters

• CROSS COMPATIBLE: Backward compatible with all Powerline 600, 500, and 200 adapters

More from the Manufacturer

The Powerline 500 AV Adapter Kit with Built-In Outlet, model TPL-407E2K, uses existing electrical lines to create a high-speed network. Two adapters are needed to start a network. Connect one adapter to your router and plug another adapter into an outlet on your electrical system for instant high-speed network access. The compact form factor saves space and offers an additional electrical outlet.

Powerline 500 AV Adapter Kit with Built-In Outlet

Includes two TPL-407E adapters

Powerline 500 networking

Never lose an electrical outlet with the built-in socket

Connects over electrical lines

Two adapters are needed to start a network.

Compact form factor saves space

Easy Installation

NDAA compliant

General description

Plug in installation

Just plug in TRENDnet adapters. The encrypted Powerline signal connects automatically through an existing electrical system.

Integrated output.

With so many devices that need power, you don't lose an outlet when you plug it in. Connect the adapter to an electrical outlet, and then connect a power strip to the adapter.

Network stability

Internet service providers prefer ultra stable Powerline networks.

Adapters

Includes two TPL-407E adapters

Powerline 500

Powerline networking over existing electrical lines**

Built-In Outlet

Never lose an electrical outlet with the built-in socket-Plug the adapter into an outlet, then plug in other devices

Noise Filter

Advanced electrical noise filter boosts performance

Multiple Adapters

Two adapters are needs to start a network-use up to 8 adapters

Easy Installation

Simply plug in the adapters

Cross Compatible

Backward compatible with all Powerline 600, 500, and 200 adapters

Sync Button

Press the Sync button to change existing encryption keys

Energy Savings

Power Save mode reduces electrical consumption by up to 80%

SPECIFICATIONS

Standards

IEEE 802.3

IEEE 802.3u

IEEE 802.3x

IEEE 1901

Device Interfaces

Ethernet port

Sync / reset button

Status LEDs

Power plug

A: North America Type B (NEMA 5–15)

EU: Euro Type C (CEE 7/16)

UK: United Kingdom Type G (BS 1363)

Frequency Band

2 – 68 MHz

Data PHY Rate

500 Mbps

Networking Distance

Up to 300 m (980 ft.) linear distance over electrical power lines

Encryption

128-Bit AES (Advanced Encryption Standard)

Optional Utility: OS Compatibility

Windows

10, 8.1, 8, 7, Vista, XP

Nodes

Up to 8 (max.)

Overlapping Powerline Networks

Up to 4 (per electrical system)

Outlet Current

110V AC, 20A (max.)

220V AC, 16A (max.)

Power

Input: 100 – 240 V AC, 50/60 Hz

Consumption: Active mode: 2.7 Watts (max.); Standby mode: 0.34 Watts (max.)

Operating Temperature

0 – 40 °C (32 – 104 °F)

Operating Humidity

Max. 90 % non-condensing

Certifications

CE

FCC

Dimensions

112 x 68 x 40 mm (4.4 x 2.7 x 1.1 in.)

Weight

A: 104 g (3.7 oz.)

EU: 190 g (6.7 oz.)

UK: 190 g (6.7 oz.)

Warranty

3 year limited

PACKAGE CONTENTS

2 x TPL-407E

Quick Installation Guide

2 x Network cable (1.5 m / 5 ft.)

* Maximum of 8 adapters (nodes) recommended for streaming video across your network.

** 500 Mbps is the maximum theoretical Powerline data rate. Actual throughput will vary depending on environment. Networked Powerline devices need to be plugged into power outlets that are on the same electrical system. GFCI outlets and AFCI circuit breakers may degrade Powerline network signals.

Do not use this unit with a power strip that is powering other devices. Max voltage cannot exceed 120V AC, 10A.

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
