24 V DC, 48 V DC Input - 54 V DC Output - 75 W - Gray
SKU
Category
Power Injectors/Splitters
MSRP$500.50
$459.09
Save 8%
Back-ordered
Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Oct 4 and Nov 8, then process your delivery right after.
Genuine Perle Systems through authorized distribution — NDAA §889 screened before checkout. TAA verified on request.
SKU
Category
Power Injectors/Splitters
Overview
INJ 2100-T PoE Injectors are DIN Rail mounted single port, PoE mid-span injectors . In environments vulnerable to voltage surges, it acts as an intermediary devices between a non-PoE switch and a PoE device to inject fully compliant power over the Ethernet cable. With electrical isolation of the internal power supply, the INJ-2100-T units are protected against short circuits on the PoE side. The integrated surge protection increases system availability by protecting the connected end devices.
Generating up to 60 Watts , the INJ-2100-T provides electrical power to remote PD access points , pan-tilt and zoom (PTZ) cameras and video-phones . It complies with the IEEE802.3bt Hi-PoE (60W of power) or IEEE 802.3at PoE+ (30W of power) standards and is also backward compatible with IEEE802.3af PoE (15.4W of power).Learn more about PoE.
With the INJ-2100-T, there is no need to buy an expensive PoE switch or install electrical wiring and outlets in hard to reach locations. Just use and open port on an existing non-PoE switch to save time and money by sending power and data over the same cable.
Specifications
General Information
Manufacturer
Perle Systems, Inc
Manufacturer Part Number
27030148
Brand Name
Perle
Product Series
INJ
Product Model
INJ 2112-T
Product Name
INJ INJ 2112-T PoE Injector
Product Type
PoE Injector
Physical Characteristics
Color Family
Gray
Product Color
Gray
Form Factor
Din Rail
Height
5.1"
Width
1.2"
Depth
4.7"
Weight (Approximate)
11.45 oz
Power Description
Input Voltage
24 V DC, 48 V DC
Maximum Output Voltage
54 V DC
Maximum Input Current
4.20 A
Maximum Output Power
75 W
Technical Information
Protection Type
Surge Protection, Over Current
Miscellaneous
Certifications & Standards
IEEE 802.3bt
IEEE 802.3at
IEEE 802.3af
EMC Directive 2014/30/EU
CE-compliant
EN 61000-4-2
EN 61000-4-3
EN 61000-4-4
EN 61000-4-6
IEC 61643-21
cULus Listed
cUL Listed
UL Listed
Environmentally Friendly
Yes
Environmental Compliance
Registration, Evaluation, Authorization and Restriction of Chemicals (REACH), China Restriction of Hazardous Substances (China RoHS)
