Thunderbolt 3 (40Gb/s) - 1x Thunderbolt Host Port With Up To 85W PD - 1x Thunderbolt - 1x 10GbE (AVB Supported) - 1x USB-C (10Gb/s) - 3x USB-A (10Gb/s) - 1x DisplayPort - 1x SD 4.0 Reader - 1x CFexpress Type B Reader - 2 Year Limited Warranty
Request pricing
Confirmed with stock and TAA status before any payment.
Genuine Other World Computing through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
High-Bandwidth and Flexibility for Demanding Hi-Res Needs
Pro-level docking stations should be ready to handle any situation that you encounter in a production workflow. The OWC Thunderbolt Pro Dock is your on-location and post-production "mission control" with an unrivaled combination of super-fast 10Gb/s Ethernet, CFexpress and SD card readers, two Thunderbolt ports, one USB-C port, and three USB-A ports.
With this unique productivity enhancing configuration, you can ingest RAW video and photo files at speeds up to 1630MB/s. Collaborate in a shared workflow environment via the 10Gb Ethernet port to keep your projects streaming from file setup to final renders with headroom to spare. View projects in greater detail with an 8K display or create a panoramic dual 4K display. Daisy chain up to five Thunderbolt devices. All while powering your laptop and managing the typical USB devices you need to get the job done.
Add Media Versatility to DIT Carts
When you're on location, your cart needs the power of versatility. With conveniently accessible front-side CFexpress and SD 4.0 card readers, the Thunderbolt Pro Dock helps you manage multiple card uploads efficiently. It's a huge asset when you're covering live events like conferences, festivals, and concerts where you're working with multiple videographers and photographers.
Calm and Connected
In addition to eliminating the on-set or in studio chaos of multiple connections, the Thunderbolt Pro Dock's solid aluminum fanless design lets you work in calm silence...even when transferring a huge file over a network.
Pro Audio Video AVB Ready
Time-sensitive data such as audio and video media streams require Audio Video Bridging (IEEE 802.1Qav, AVB) ready gear. No sweat... you can stream vast volumes of high-quality data to multiple destinations in real-time with very low latency over existing network cable via the Thunderbolt Pro Dock's 10Gb Ethernet port.
Small Footprint, Big Connections
Sized similarly to a single external drive enclosure, the Thunderbolt Pro Dock's aluminum case helps keep cart weight streamlined while easily fitting into a cart drawer or small box during cart breakdown.
With two Thunderbolt 3 ports, the Thunderbolt Pro Dock offers incredible potential to connect multiple devices to take on the biggest projects. You can daisy-chain up to 5 additional Thunderbolt devices to the Thunderbolt Pro Dock for studio-level storage, RAID arrays, PCIe expansion units, or all of these combined and connected at 40Gb/s bandwidth.
Meet the challenges of any workflow with these Thunderbolt Pro Dock add ons:
• ThunderBlade: the ultimate on-site workflow drive
• ThunderBay: high-capacity RAID workstation
• OWC Express 4M2: compact, customizable 4-bay RAID array
• Envoy Pro FX: rugged and fast bus-powered portable SSD Card Use
More from the Manufacturer
The best networking, media, and docking for pro video production and demanding data workflows.
Fast & diverse: transfer files in a blink, daisy chain up to five Thunderbolt devices, use USB-C accessories, and add an HDMI display with two Thunderbolt (USB-C) ports
Full throttle bandwidth: share and stream up to 90% faster with a 10Gb/s Ethernet port
AVB ready: perfect for use in pro audio and video applications where synchronization of data streams is critical
Ingest content: easily handle multiple video and photo card uploads at up to 1630MB/s with CFexpress and SD card readers
Full speed connectivity: use your devices and accessories at their max speed with one USB-C and three USB Type A 10Gb/s ports
Add more viewspace: connect two 4K displays or up to a single 8K display via Displayport 1.4
Powerful: keep your notebook mobile use ready with 85W charging power
Silent and secure: fanless cooling mode and locking power connection for on-set use
Thunderbolt certified: for Mac and Windows
Innergize™ Enabled: custom OWC software for complete health, performance, and field upgrade management when using OWC Atlas Memory Cards with OWC Atlas Card Readers and card reader-equipped products
Dante compatible: easy Plug and Play - no software needed - into networks designed for bit perfect audio with super low latency and sample accurate synchronization
High-Bandwidth and Flexibility for Demanding Hi-Res Workflow Needs
Pro-level docking stations should be ready to handle any situation that you encounter in a production workflow. The OWC Thunderbolt Pro Dock is your on-location and post-production “mission control” with an unrivaled combination of super-fast 10Gb/s Ethernet, CFexpress and SD card readers, two Thunderbolt ports, one USB-C port, and three USB-A ports.
With this unique productivity enhancing configuration, you can ingest RAW video and photo files at speeds up to 1630MB/s. Collaborate in a shared workflow environment via the 10Gb Ethernet port to keep your projects streaming from file setup to final renders with headroom to spare. View projects in greater detail with an 8K display or create a panoramic dual 4K display. Daisy chain up to five Thunderbolt devices. All while powering your laptop and managing the typical USB devices you need to get the job done.
Add Media Versatility to DIT Carts
When you’re on location, your cart needs the power of versatility. With conveniently accessible front-side CFexpress Type B and SD 4.0 card readers, the Thunderbolt Pro Dock helps you manage multiple card uploads efficiently. It’s a huge asset when you’re covering live events like conferences, festivals, and concerts where you’re working with multiple videographers and photographers.
Calm & Connected
In addition to eliminating the on-set or in studio chaos of multiple connections, the Thunderbolt Pro Dock’s solid aluminum fanless design lets you work in calm silence…even when transferring a huge file over a network.
AVB Ready and Dante Compatible
Time-sensitive data such as audio and video media streams require Audio Video Bridging (IEEE 802.1Qav, AVB) ready gear. No sweat… you can stream vast volumes of high-quality data to multiple destinations in real-time with very low latency over existing network cable via the Thunderbolt Pro Dock’s 10Gb Ethernet port.
Not only that, the Thunderbolt Pro Dock is also Dante compatible. This means easy Plug and Play - no software needed - into networks designed for bit perfect audio with super low latency and sample accurate synchronization.
Small Footprint, Big Connections
Sized similarly to a single external drive enclosure, the Thunderbolt Pro Dock’s aluminum case helps keep cart weight streamlined while easily fitting into a cart drawer or small box during cart breakdown.
With two Thunderbolt 3 ports, the Thunderbolt Pro Dock offers incredible potential to connect multiple devices to take on the biggest projects. You can daisy-chain up to 5 additional Thunderbolt devices to the Thunderbolt Pro Dock for studio-level storage, RAID arrays, eGPUs for graphics processing, or all of these combined and connected at 40Gb/s bandwidth.
Meet the challenges of any workflow with these Thunderbolt Pro Dock add-ons:
OWC ThunderBlade - the ultimate on-site workflow drive
OWC ThunderBay 4 - high-capacity RAID workstation
OWC Express 4M2 - compact, customizable 4-bay RAID array
OWC Envoy Pro FX - rugged and fast bus-powered portable SSD
OWC Mercury Helios 3S - high-end PCIe video, audio, and SSD card use
Conquers Workflows and Combats Clutter
When you’re back in your office or studio, the Thunderbolt Pro Dock has the power and ports you need to manage your workflow and take control of your workspace. The Thunderbolt Pro Dock is compact, so you can comfortably manage your peripherals and keep your workspace free of clutter. Its 10Gb Ethernet connection keeps you connected at top speeds, and with 85W charging power, your notebook is charged up and ready to move.
OWC Thunderbolt Cable Included
OWC Thunderbolt Pro Dock comes with a certified 0.7M OWC Thunderbolt Cable. But if your workflow demands a different length to make the connection, OWC Thunderbolt (USB-C) Cables are the perfect choice.
Disconnect in One Click
Safely disconnect multiple drives in a single click. OWC Dock Ejector was designed by OWC hardware and software engineers to ensure all data is written before disconnection, saving time and protecting against data loss. It makes losing your hard-earned work a thing of the past.
Stabilize Thunderbolt and USB-C Cables
Active workspaces expose gear to bumps, shoves, or even the random tail wag from a pet. OWC ClingOn custom cable stabilizers (sold separately) screw into the OWC Dock or OWC Drive housing to reduce – if not completely eliminate – cable strain on Thunderbolt and USB-C connections so you can work with confidence even in the highest traffic environments.
Innergize Your Workflow with Highest Performance and Reliability
OWC Innergize™ is the first stage of the Capture to Completion™ ecosystem of OWC products designed to seamlessly propel professional photographers, videographers, and content creators to the highest level of workflow performance and reliability. This OWC custom-designed app is a complete health, performance, and field upgrade management tool when using OWC Atlas memory cards with OWC Atlas readers and reader equipped products.
Work with Maximum Confidence and Reliability
Health
Over time and use cycles, flash memory does wear out. Innergize verifies and reports the percentage of use life remaining. Now you can work with full confidence your OWC flash memory product will deliver the reliability you can trust.
Sanitize
Writes, deletes, and formatting all take their toll on memory cards. Innergize cleans and restores the flash memory performance of OWC memory cards so you can get the best results on every use.
Field Upgrade
When new cameras or firmware updates to existing cameras are introduced, they may not work properly with flash memory cards and drives. Innergize gives OWC memory card users the ability to quickly upgrade their firmware in the field for full compatibility, additional performance enhancements, and bug fixes for optimal reliability.
Limited Warranty: 2 Year
About OWC For more than 35 years, OWC has had a simple goal. To create innovative DIY solutions to give you the most from your technology. At OWC, we feel that technology can be instrumental in changing the world for the better if it’s done right. Whether you use it to communicate, create, or safeguard, we believe that technology should be simple, affordable, and easy to use. It should just work and do what you need it to do. At OWC, it is our mission to deliver that seamless level of experience to you with every solution that we make, and in every interaction that we have. We are working to build a better world through our solutions, and it is our mission to create solutions that improve the lives of everyone that touches them. At OWC we promise to: Respect your time. Whether that is through our solutions that aim to get the tech out of the way and keep it out so you can focus on what’s important to you or through our service getting you the advice or help you need. Maximize your budget. That means in the short term in having fair prices, but most importantly in the long term by focusing on quality solutions that are built to last. Our solutions aren’t the cheapest because we know how much of a pain it is to swap out parts in your set up and we know how much you rely on your OWC gear. Support you. Every solution is backed and supported by knowledgeable representatives, not just before the sale, but during and after. You can always call, email or chat with OWC over the lifetime of the product. And that support is always free (outside of the few noted exceptions). Educate. It’s a fast moving world out there. We geek out on the tech so you don't have to. Our solutions help make complicated tasks fast and easy, our install videos demystify and our blog helps you do more with what you have and wade through the marketing-speak. Give it our all. All components in our solutions go through a strict qualification process to make sure they will perform as needed. External drive solutions are additionally tested after assembly, with some tests taking hours or even days to certify that they will go the distance. Channel you. Our solutions are tested using many different workflows so we can ensure when you plug it in, it just works. Complete the circle. There are many, many different options out there and while our hardware and software solutions are designed to work together, they are also designed to work within your setup. What We Do We empower our customers to take their technology further and ensure the investment that they made a couple years ago doesn’t have to be thrown out the door and recycled for something new. How It All Started “I started OWC because it was difficult for me to get to a local store to upgrade my own Apple. On top of that, it was very very expensive to do so and it drove me to number one do my own updgrades, but share that information and offer these upgrades so that others can benefit the same.” Environmental Sustainability We have worked tirelessly to build sustainable practices into all levels of our business operations. Join Our Team At OWC we strive to empower our customers through groundbreaking advancements in upgrades and solutions for Mac, PC, and mobile devices. With an emphasis on superior service, quality, value, and environmental responsibility, we are committed to the creation of technology that inspires the imagination and a world where everything is possible.
| Package Contents |
|
|---|---|
| Host Interface | Thunderbolt 3 |
| Product Type | Docking Station |
| Device Supported | Notebook, Monitor |
| Manufacturer Part Number | OWCTB3DKPRO |
| Packaged Quantity | 1 |
| Limited Warranty | 2 Year |
| Weight (Approximate) | 1.41 lb |
| Connectivity Technology | Wired |
| Manufacturer | Other World Computing |
| Product Name | Thunderbolt Pro Dock |
| Brand Name | OWC |
| Operating System Supported | Windows 10 (64-bit), Windows Server 2016, Windows 11, iPadOS, Mac OS X 12.x Monterey, Mac OS X 13.x Ventura, Mac OS X 14.x Sonoma |
| Memory Card Supported | CompactFlash, SD |
| Country of Origin | Taiwan |
| Height | 1.38" |
| Width | 8.35" |
| Memory Card Reader | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Network (RJ-45) | Yes |
| Maximum Power Supply Wattage | 180 W |
| DisplayPort | Yes |
| Thunderbolt | Yes |
| Number of Displays Supported | 3 |
| Number of DisplayPorts | 1 |
| Number of RJ-45 Ports | 1 |
| Kensington Security Slot | Yes |
| Number of Thunderbolt 3 Ports | 2 |
| USB Type-C | Yes |
| USB Type-C Detail | 1 x USB 3.2 Gen 2 Type-C Port up to 10Gb/s (1250MB/s) - USB 2.0/3.0 backwards compatible |
| DisplayPort Version | 1.4 |
| Number of USB Type-C Ports | 1 |
| Product Color | Black |
| Supported Resolutions | 3840 x 2160, 5120 x 2880, 7680 x 4320 |
| Number of USB 3.2 Gen 2 Type-A Ports | 3 |
| USB Type-A | Yes |
| Screen Mode Supported | 4K, 5K, 8K |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
