Club 3D USB Gen 1 Type-C 8-in-1 MST Dual 4K60Hz Display Travel Dock
for Headset, Desktop PC - Charging Capability - Memory Card Reader - SD, microSD - USB (Gen 1) Type C - 2 Displays Supported - 4K @ 60Hz, 8K @ 30Hz - 3840 x 2160, 7680 x 4320 - 4 x USB Ports - 2 x USB Type-A Ports - USB Type-A - 2 x USB Type-C Ports - USB Type-C - 1 x RJ-45 Ports - Network (RJ-45) - HDMI - DisplayPort - Wired - Gigabit Ethernet - Windows, macOS - 100W
SKU
Category
Docking Stations
$78.73
Back-ordered
Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Oct 27 and Dec 1, then process your delivery right after.
Genuine Club 3D through authorized distribution — NDAA §889 screened before checkout.
SKU
Category
Docking Stations
Overview
The Club 3D CSV-1597 USB Gen 1 Type-C 8-in-1 MST Dual 4k60Hz Display Travel Dock with HDMI?8K30Hz(HDR), DisplayPort 8K30Hz, 2x USB Gen1 Type-A, BC1.2, RJ45, SD/Micro SD card slots and USB Gen1 Type-C PD3.0 Female port, provides a very advanced, efficient solution to extend a single USB Gen1 Type-C port to be multiple ports. It integrates video, data and power ports that allows to connect 2 displays simultaneously for enjoying videos on a larger screen, connect multiple USB Gen1 devices for data transmission up to 5Gbps, connect a Gigabit Ethernet source for getting your PC connected to super high speed network, or connect to headset to enjoy fantastic music. It also provides PD3.0 charging for support up to max. 100W PD charging. This is for operating this device and charge the host simultaneously. It can work on all DP?1.4 Alt mode supported USB Gen1 Type-C hosts.
Highlights
Support DP?1.4 Alt mode max. 8K@30Hz(with DSC1.2)
Support HDMI max. 8K@30Hz(with DSC1.2)
Support Dual display HDMI?+ DP max.4K60Hz (MST with DSC1.2)
Max 5Gbps data transmission per USB Gen 1 Type-A port
Support max 7.5W(5V/1.5A) downstream charging, 2 USB Gen1 Type-A share max 2.5A(12.5Watt) output
Support Gigabit Ethernet 10M/100M/1000M
Support SD3.0 UHS-I up to 832Mbps/104MB/s data rate, allow 2 card slots to work simultaneously
Support PD3.0 with max. 100W PD charging
Specifications
General Information
Manufacturer
Club 3D
Manufacturer Part Number
CSV-1597
Brand Name
Club 3D
Product Name
USB Gen 1 Type-C 8-in-1 MST Dual 4K60Hz Display Travel Dock
Packaged Quantity
1
Product Type
Docking Station
Interfaces/Ports
Host Interface
USB (Gen 1) Type C
Total Number of USB Ports
4
Number of USB Type-C Ports
2
USB Type-A
Yes
USB Type-C
Yes
USB Type-C Detail
USB Gen 1 Type-C Male (Connect to host),1 x USB Gen 1 Type-C Female
