Advantech FPM-715W-P9AE 16" Class LED Touchscreen Monitor - 16:9
15.6" Viewable - Projected Capacitive - 10 Point(s) Multi-touch Screen - 1920 x 1080 - Full HD - Thin Film Transistor (TFT) - 16.7 Million Colors - 450 Nit - LED Backlight - HDMI - USB - VGA - DisplayPort
SKU
Category
Touchscreen Monitors
$1,304.74
Back-ordered
Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Oct 4 and Nov 8, then process your delivery right after.
Genuine Advantech through authorized distribution — NDAA §889 screened before checkout. TAA verified on request.
SKU
Category
Touchscreen Monitors
Country of origin
China
Country of origin is manufacturer-reported and can vary by production lot. Where TAA applies to your purchase, we verify the shipping unit's origin on request.
Overview
In IIoT and Industry 4.0, more and more customers need data to be visualized to help process management and decision making. The FPM-715W/FPM-721W/FPM-724W are industrial-grade, widescreen monitor with sleek, simple lines and a true-flat touchscreen. Equipped with P-CAP 10-point multi-touch control and an IP66-rated front bezel,FPM-715W series is specifically designed for industrial applications. Moreover, FPM-715W/FPM-721W support a wide operating temperature range (-20 ~ 60 °C/-4 ~ 140 °F) and various mount options to make these monitors ideal for factory and machine automation display applications.
More from the Manufacturer
FPM-715W
15.6" Full HD Industrial-grade, widescreen Monitor with P-CAP 10-point multi-touch Control, Direct HDMI, DP and VGA Ports
15.6" Full HD TFT LED LCD with true-flat touchscreen
16:9 wide screen aspect ratio, increases viewing area by 40%
Supports 10-point multi-touch control via USB interface in Windows 7/8/10 OS
Slim design enables easy installation
Supports various mount options: panel, desktop, and VESA arm
Touchscreen with reliable glass surface and P-CAP touch control
Robust system with Die-casting aluminum chassis and IP66-rated aluminum alloy front bezel
Lockable I/O connectors
Supports various mount options: panel, wall, desktop, rack or VESA arm mounting
Highlights
15.6"/21.5"/23.8" Full HD TFT LED LCD with true-flat touchscreen
16:9 wide screen aspect ratio, increases viewing area by 40%
Supports 10-point multi-touch control via USB interface in Windows 7/8/10 OS
Slim design enables easy installation
Supports various mount options: panel, desktop, and VESA arm
Touchscreen with reliable glass surface and P-CAP touch control
Robust system with Die-casting aluminum chassis and IP66-rated aluminum alloy front bezel
Lockable I/O connectors
Supports various mount options: panel, wall, desktop, rack or VESA arm mounting
Specifications
General Information
Manufacturer
Advantech Co., Ltd
Manufacturer Part Number
FPM-715W-P9AE
Brand Name
Advantech
Product Series
FPM-715W
Product Model
FPM-715W-P9AE
Product Name
FPM-715W-P9AE Touchscreen LED Monitor
Product Type
LED Touchscreen Monitor
Interfaces/Ports
HDMI
Yes
USB
Yes
VGA
Yes
DisplayPort
Yes
Physical Characteristics
VESA Mount Compatible
Yes
VESA Mount Standard
75 x 75
Height
10.6"
Width
16.5"
Depth
2"
Weight (Approximate)
8.82 lb
Power Description
Maximum Power Consumption
12.71 W
Technical Information
Screen Size Class
16"
Viewable Screen Size
15.6"
Screen Mode
Full HD
Panel Technology
Thin Film Transistor (TFT)
Aspect Ratio
16:9
Horizontal Viewing Angle
160°
Vertical Viewing Angle
160°
Mount Type
Stand Mountable, Wall Mountable, Panel Mount, Arm-mountable, Desk Mountable, Rack-mountable
Backlight Technology
LED
Features
Anti-glare
Ingress Protection (IP) Rating
IP66
Glass Hardness
7H
Touchscreen Information
Touchscreen Type
Projected Capacitive
Multi-touch Screen
Yes
Number of Simultaneous Touchpoints
10
Video
Maximum Resolution
1920 x 1080
Color Supported
16.7 Million Colors
Native Contrast Ratio
500:1
Brightness
450 Nit
Environmental Conditions
Operating Temperature Range
-4°F (-20°C) to 140°F (60°C)
Miscellaneous
Package Contents
FPM-715W-P9AE Touchscreen LED Monitor
1 x Terminal Block
10 x Clamper
10 x Clamper Screw
1 x GND Cable
1 x USB Touch Cable
1 x VGA Cable
7 x HDMI and DP Lockable Kit
Country of Origin
China
Environmental Compliance
Taiwan Restriction of Hazardous Substances (Taiwan RoHS)
