SIIG 2 Port HDMI 2.0 4K HDR Splitter / Switcher with IR Remote
18Gbps video bandwidth - 2 port HDMI input switcher or 1x2 HDMI splitter - Up to 4K60Hz 4:4:4 8-bit or 4K60Hz 4:2:0 10 bit HDR - EDID management - Downscaling 4K60Hz to 1080p 60Hz - HDCP 2.2/1.4 - 3.5mm 2ch audio or HDMI 7.1 ch audio - LED indicators - Micro USB FW update and power in - included power supply and Micro USB cable - Function button switch - Metal housing - IR Remote Control - Mountable design - 2 years warranty
Genuine SIIG through authorized distribution — NDAA §889 screened before checkout.
SKU
Category
Signal Splitters/Amplifiers
Country of origin
China
Country of origin is manufacturer-reported and can vary by production lot. Where TAA applies to your purchase, we verify the shipping unit's origin on request.
Overview
Share two 4K HDMI displays (mirror mode) between two 4K HDMI sources with IR remote control switching and EDID management
• Distributes HDMI video and audio from two HDMI sources to up to 2 HDMI displays simultaneously while maintaining signal quality
• Compliant with HDMI 2.0a, HDCP 2.2/1.4 with 18Gbps bandwidth
• Supports resolutions up to 4Kx2K@60Hz (YUV 4:4:4 8-bit), 3D, HDR, 36-bit Deep Color
• Supports LPCM 7.1, Dolby TrueHD, Dolby Digital Plus, and DTS-HD Master Audio
• Supports stereo audio extraction to 3.5mm audio output jack for 2ch stereo source devices only
• Auto video scaling feature, via HDCP detection of your connected display, detects and configures the video resolution automatically according to the capabilities of the connected monitors
• High quality materials and metal housing extends the stability and durability, allowing for long hours of operation
• Built-in EDID management and firmware update mechanism further expands compatibility
• EDID modes are controlled by the included remote control, push button control cycles between Auto EDID, Copy EDID, and Mixed EDID modes
• Individual LED indicators for power and EDID mode allow for easy and quick operating status
Compatibility Notes :
- 4K@30Hz monitors will display in 1080p @60Hz resolution
- Does not support 4K/60Hz YUV 422 down scaling
- The 2 HDMI outputs mirror each other, extended displays are not supported
