SKU
GVE4K60KIT
Category
Audio & Video Consoles/Extenders
Overview
Extend or Split Video Transmission over Cat 6
IOGEAR's 4K Video Extender/Splitter Over CAT 6 Kit is the perfect choice for users who wish to extend or split video over longer lengths than HDMI® cables can handle without video degradation issues. HDMI cables max out at 50 ft, while CAT 6 can extend to 230 ft (165 ft between receivers). CAT 6 cables are more efficient to run through walls, attics and crawl spaces. And, CAT 6 cables are 60% less expensive than HDMI cables and are less likely to fail over time.
Extender Mode VS Splitter Mode
Extender Mode: The major benefit of this mode is it allows you to extend the distance between two devices without loss of video quality. For example, you want to view a film on a Blu-ray? player but in a different room--extender mode makes this connection possible.
Splitter Mode: The major benefit of this mode is taking one source video and playing it on many receiving screens. For example, in an office/store setting, you have multiple monitors that need to play the same video and are rather far in distance from each other. Cascade up to 10 display devices with 10 receivers.
4K Video Quality
Enjoy cinema-quality video. This 4K extender kit transmits resolutions up to 4096 x 2160 @30Hz or 3840 x 2160 @60Hz (4:4:4) with 18 Gbps bandwidth, with close to zero latency.
Superior Audio Quality
IOGEAR's 4K Video Extender/Splitter Kit includes the S/PDIF port to support LPCM, DTS-HD®, DTS®, Dolby® TrueHD 7.1, Dolby® Digital 5.1 audio formats. With the flip of a switch, select ARC for returning audio from compatible displays. An HDMI loop-out allows an additional display to be connected on the transmitter side.
More from the Manufacturer
Highlights
Extend video to a single display, or add addtional receivers to cascade video to multiple displays (up to 10)
Supports resolutions up to 4096 x 2160 @30Hz or 3840 x 2160 @60Hz (4:4:4)
Near zero latency (1ms) allows use for gaming or other low latency dependent uses
Transmitter features HDMI output for local display connection
Only 1 transmitter is needed to cascade up to 10 receivers
Range of 230 ft. to the first receiver and 165 ft. between all cascading receivers
S/PDIF connection for external digital audio
Bi-directional IR capability allows soure unit control from display and display control from source (additional IR receiver and emitter required for full bi-directional functionality
Aluminum housing
Electrostatic protected
Specifications
Application/Usage
Display
Package Contents
1 x Transmitter Unit
1 x Receiver Unit
2 x IR Extension Cables
2 x Power Adapters
2 x Mounting Kits
1 x User Guide
1 x Warranty Card
Product Type
Video Extender Transmitter/Receiver
Manufacturer Part Number
GVE4K60KIT
Limited Warranty
3 Year
Connectivity Technology
Wired
Manufacturer
IOGEAR, Inc
Product Name
4K Video Extender/Splitter over Ethernet Cable Kit
Brand Name
IOGEAR
Graphics Modes
4K
Environmentally Friendly
Yes
Maximum Video Resolution
4096 x 2160
Twisted Pair Cable Standard
Category 6
Maximum Operating Distance
230 ft
Number of Network (RJ-45) Ports
2
Network (RJ-45)
Yes
Number of HDMI Inputs
1
Number of HDMI Outputs
2
HDMI In
Yes
HDMI Out
Yes
Media Type Supported
Twisted Pair
Number of Output Devices Supported
2
Number of Input Devices Supported
1
Transmitter Height
0.75"
Transmitter Width
4.13"
Transmitter Depth
4.13"
Receiver Height
0.75"
Receiver Width
4.13"
Receiver Depth
4.13"
Transmitter Weight (Approximate)
1.10 lb
Receiver Weight (Approximate)
1.10 lb
Remote (IR) Output
1
Remote (IR) Input
1
Environmental Compliance
Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
