Genuine Icy Dock through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
MB031U-1SMB
Category
Drive Cabinets
Overview
The EZ-Adapter MB031U-1SMB provides users the quickest and the easiest way to access their 2.5-inch SATA HDD/SSD or M.2 SATA SSD through any systems equipped with the USB port. It supports transfer speeds up to 5Gbps via USB 3.2 Gen 1 and backward compatible with the previous USB 2.0 interface for best system compatibility. The MB031U-1SMB is compact and ultra-portable that is small in size but with surprisingly rich features.
Quick and Easy Drive Swap
Simply connect the 2.5-inch or M.2 SATA drive* to the EZ-Adapter and then plug the USB type C to A cable into the system to immediately start the data transfer. The tool-less drive installation allows the MB031U-1SMB to swap multiple hard drives or SSDs within seconds, making the process quick and easy.
Open-air Design
The open-air design allows 2.5" and M.2 drive to be fully exposed for best passive heat dissipation.
Data Transfer On the Go
The EZ-Adapter MB031U-1SMB has been engineered for mobility but does not compromise functionality and durability. The adapter is made out of lightweight but durable ABS plastic with a smooth finish that will not damage other equipment when it's placed in your carry-on bag. The compact design allows the adapter to be carried everywhere without taking up too much space.
Ultimate Compatibility
The EZ-Adapter comes with a USB type C to A cable and supports data transfer speeds up to 5Gbps via USB 3.2 Gen 1 port. It's backward compatible with the USB 2.0 ports that often available on legacy PC/Mac systems and other devices such as DVR, Smart TV, and Android TV Box. The EZ-Adapter supports plug and plays technology with no driver required.
Power Switch & LED Indications
The EZ-Adapter is equipped with a LED indicator light that shows the drive power and activity. The individual slide power switch allows users to power off the drive when it is not used to reduce drive usage and conserve power consumption.
Warranty
Limited Warranty: 3 Year
Highlights
Supports 1x 2.5" SATA HDD/SSD or SATA M.2 SSD
Support transfer speeds up to 5Gbps via USB 3.2 Gen 1
Backward compatible with USB 2.0 interface
Cool blue drive activity LED indicator light
Large on/off drive power switch
Anti-Slip rubber foot pad to ensure the adapter does not slip on the surface
Included USB Type C to A cable
Industry-leading 3-year warranty with complimentary tech support & customer service.
Specifications
General Information
Manufacturer
Icy Dock
Manufacturer Part Number
MB031U-1SMB
Brand Name
Icy Dock
Product Line
EZ-Adapter
Product Model
MB031U-1SMB
Product Name
2.5" & M.2 SATA Hard Drive/SSD to USB 3.2 Gen 1 Adapter
Product Type
Drive Enclosure
Interfaces/Ports
Drive Interface
SATA, M.2
Host Interface
USB 3.2 (Gen 1) Type C
Network & Communication
Wireless LAN
No
Physical Characteristics
Color Family
Black
Product Color
Black
Product Material
Acrylonitrile Butadiene Styrene (ABS), Plastic
Form Factor
External
Height
2.4"
Width
3.6"
Depth
0.7"
Weight (Approximate)
0.65 oz
Technical Information
Number of Hard Drives Supported
1
Number of Hard Drives Installed
0
Number of Solid State Drive Supported
1
Number of Solid State Drive Installed
0
I/O Expansions
Number of Total Expansion Bays
1
Number of 2.5" Bays
1
Warranty
Limited Warranty
3 Year
Miscellaneous
Package Contents
2.5" & M.2 SATA Hard Drive/SSD to USB 3.2 Gen 1 Adapter
User Manual
USB 3.2 Gen 1 Type C to A Cable
Country of Origin
China
Environmentally Friendly
Yes
Environmental Compliance
Restriction of Hazardous Substances (RoHS), Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
