APC by Schneider Electric Easy UPS SRV 2kVA Tower UPS
Tower - 4 Hour Recharge - 120 V AC Input - 120 V AC, 115 V AC, 120 V AC Output - Single Phase - Sine Wave - Serial Port - 4 x NEMA 5-20R Receptacle(s) - 4 x Battery/Surge Outlet
SKU
Category
General Purpose UPS
Request pricing
Confirmed with stock and TAA status before any payment.
Genuine Schneider Electric through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
Category
General Purpose UPS
Overview
High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions
For small to medium businesses, APC by Schneider Electric delivers a new category of UPSs designed for essential power protection needs even in the most unstable power conditions. APC Easy UPS 1 Ph Online is a versatile, high quality, cost competitive UPS developed to handle a wide voltage range, inconsistent power conditions and delivering the quality millions of IT professionals trust around the world.
Warranty
Limited Warranty: 2 Year
Highlights
Automatic internal bypass - Pure static bypass switch without bridging contactor securing a fast and reliable transfer to and from bypass, rated for 125% nominal load.
Automatic restart of loads after UPS shutdown - Automatically starts up the connected equipment upon the return of utility power.
ECO Mode - Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection
Input Power Factor Correction - This product has a power factor corrected input side ensuring that the input power factor is always 1 regardless of load and mains voltage. A power factor of 1 minimizes installation costs by allowing the use of smaller cables and smaller fuses.
Intelligent battery management - Maximizes battery performance, life, and reliability through intelligent, precision charging.
Intelligent SmartSlot - Mini slot supports various optional management cards which provide basic or essential monitoring, management and control features for the UPS.
LCD graphics display - Text and mimic diagrams that display modes of operation, system parameters and alarms.
Serial connectivity - Provides management of the UPS via a serial port.
USB connectivity - Provides management of the UPS via a USB port (not available on all models).
Specifications
Battery Information
Battery Characteristics
Maintenance-free, Sealed, Leak-proof
Battery Chemistry
Lead Acid
Typical Battery Recharge Time
4 Hour
Replaceable Battery
Yes
Controls/Indicators
Status Indicators
LCD Graphics Display: Modes of operation System parameters Alarms LED Indicators: Easy-to-read status of the unit Utility power conditions
Environmental Conditions
Maximum Operating Elevation
9842.52 ft
Maximum Operating Temperature
104°F (40°C)
Maximum Storage Elevation
48437.01 ft
Storage Temperature
-4°F (-20°C) - 122°F (50°C)
Operating Humidity
0% - 95%
Storage Relative Humidity
0% - 95%
General Information
Manufacturer
Schneider Electric SA
Manufacturer Part Number
SRV2KA
Brand Name
APC by Schneider Electric
Product Line
Easy UPS
Product Series
SRV
Product Name
Easy UPS SRV 2kVA Tower UPS
Product Type
Double Conversion Online UPS
Interfaces/Ports
Serial Port
Yes
USB (HID Compliant) Port
Yes
Management
Alarm
On Battery, Low Battery, Overload
Physical Characteristics
Product Color
Black
Height
9.37"
Width
5.71"
Depth
15.75"
Form Factor
Tower
Weight (Approximate)
37.48 lb
Power Description
Load Capacity (VA)
2000 VA
Load Capacity (Watt)
1600 W
Input Voltage
120 V AC
Input Voltage Range
110 V AC - 120 V AC
Output Voltage
120 V AC, 115 V AC
Input Frequency
70 Hz
Output Frequency
60 Hz
Waveform Type
Sine Wave
Surge Energy Rating
600 J
Technical Information
Receptacle Type
NEMA 5-20R
Receptacle Detail
4 x NEMA 5-20R
Number of Battery & Surge Outlets
4
Phase
Single Phase
Application/Usage
Business
Warranty
Limited Warranty
2 Year
Miscellaneous
Package Contents
Easy UPS SRV 2kVA Tower UPS
Basic UPS signalling RS-232 cable
CD with software
USB cable
User manual
Environmentally Friendly
Yes
Environmental Compliance
Restriction of Hazardous Substances (RoHS), Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
