Genuine Promise Technology through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
VTJ5800SDX16TU
Category
Drive Cabinets
Overview
Affordable | Enterprise-level Storage
Delivers an affordable high-performance SAS solution with advanced enterprise level reliability and functionality.
Four multipurpose SAS ports (SFF-8644) per controller for connecting upstream or downstream multiple cascaded JBODs for applications requiring huge bandwidth.
Fully redundant I/O modules, power supplies, and cooling units providing exceptional data availability for any size business environment.
Cable-less Storage Bridge Bay (SBB) design for Enterprise OEMs.
Data Center | Hybrid HDD/SSD Arrays
Flash arrays enable optimized speed for key enterprise applications that need processing power yet power savings.
Fully backward compatible with 6 Gb SAS/SATA devices, users have the ability to deploy 3/6/12 Gb SAS/SATA hard drives and SSDs in the J5000 Series.
Efficient power supplies provide up to 90% power efficiency that improves TCO by conserving power, reducing heat output and improving cooling costs.
Internal 12 Gb SAS expander-based architecture also allows for transparent access to each drive, enabling full utilization of the power management features built into modern hard drives.
Backup
As consumers and businesses become more mobile, the need for data access, retrieval, and distribution anywhere at any time means that data must be protected.
Data centers, hyperscale computing, and high-performance computing not only require performance and reliability, but flexibility and cost-efficiency for tiered storage management. Nearline SAS/SATA JBOD expansion units provide the versatility and scale for such demands.
Warranty
Additional Warranty Information: 3-year full system limited warranty, optional extended warranty, onsite parts replacement program
Limited Warranty: 3 Year
Highlights
Compact in size but massive in performance. Provides sufficient external data storage, with ultra-fast data transfer speeds and configurable modes.
Organize wires & secure cables for professional installation with rack mounting facility
Specifications
General Information
Manufacturer
Promise Technology
Manufacturer Part Number
VTJ5800SDX16TU
Brand Name
Promise
Product Line
VTrak
Product Series
J5000
Product Model
J5800SD
Product Name
VTrak J5800SD Drive Enclosure
Product Type
Drive Enclosure
Interfaces/Ports
Drive Interface
Serial ATA, 12Gb/s SAS
Physical Characteristics
Form Factor
Rack-mountable
Rack Height
4U
Height
6.9"
Width
17.6"
Depth
20"
Weight (Approximate)
109.35 lb
Technical Information
Number of Hard Drives Supported
24
Number of Hard Drives Installed
24
Total Hard Drive Capacity Installed
384 TB
Number of Solid State Drive Supported
24
Number of Solid State Drive Installed
0
Maximum Data Transfer Rate
12 Gbit/s
I/O Expansions
Number of Total Expansion Bays
24
Number of 3.5" Bays
24
Warranty
Limited Warranty
3 Year
Additional Warranty Information
3-year full system limited warranty, optional extended warranty, onsite parts replacement program
Miscellaneous
Environmental Compliance
Waste Electrical and Electronic Equipment Directive (WEEE), Restriction of Hazardous Substances (RoHS)
