Genuine GIGABYTE Technology through authorized distribution — NDAA §889 screened before checkout. TAA verified on request.
SKU
Category
Motherboards
Overview
Q870M D3H | Infinite Memory Performance
UD motherboards boost DDR5 memory performance and offer top-notch compatibility using various advanced methods
AI Overclocking For peak performance | AORUS AI Sntch
Auto-Overclocking Software by AI model
AI SNTCH Engine
Advanced AI Overclocking Model
Advanced AI Overclocking Model. | AI Design
For MB signal enhancement
AI-Driven PCB Design
Redefining PCB Design with AI
HyperTune BIOS
AI-Driven Advanced BIOS Optimization Technology
Durable Performance
GIGABYTE Ultra Durable motherboards built with optimal components inside out provide the prime performance and timeless platform.
Hybrid VRM Design
The best VRM design ever built with the highest quality components. Delivers enhanced system performance with ultimate hardware scalability.
Smart Fan 6
Cool. Quiet. Customized.
Warranty
Limited Warranty: 3 Year
Highlights
Compatible Core Ultra processor lets you perform all your computational tasks at a swift pace
With DDR5 SDRAM get efficient data transfer rate and enhanced computer's performance
RAID supported levels provide data reliability and fault tolerance
Supports Intel Intel HD Graphics controller for effective graphics and amazing visual quality
HDMI interface connects variety of HD devices including Gaming Controllers, Blu-ray players, laptops, PCs, digital cameras and many others for you to experience the ultimate HD display
DisplayPort host interface allows audio and video signals to be shared in a single cable transmission to ensure maximum efficiency
Retrieve a significant number of PCI slots, expansion slots, and peripheral ports that have an enhanced heat dissipation capability with the ATX desktop motherboard
With 4 USB 2.0 ports, transfer several documents without error
Specifications
Audio
Audio Channels
7.1
General Information
Manufacturer
GIGABYTE Technology, Inc
Manufacturer Part Number
Q870M D3H
Brand Name
GIGABYTE
Product Line
Ultra Durable
Product Model
Q870M D3H
Product Name
Ultra Durable Q870M D3H Desktop Motherboard
Product Type
Desktop Motherboard
I/O Controller
Controller Type
Serial ATA/600
RAID Supported
Yes
RAID Levels
0, 1, 5, 10
I/O Expansions
Total Number of Expansion Slots
3
Total Number of PCI Express Slots
3
Number of PCI Express x1 Slots
1
PCI Express Standard
PCI Express 5.0, PCI Express 4.0
Number of PCI Express x16 Slots
2
Interfaces/Ports
Total Number of USB Ports
8
Number of USB 2.0 Ports
4
Number of USB 3.2 Gen 1 Ports
3
Number of USB 3.2 Gen 2 Type-C Ports
1
HDMI
Yes
DisplayPort
Yes
Number of Network (RJ-45) Ports
2
Memory
Number of Memory Slots
4
Memory Form Factor
DIMM, UDIMM
Maximum Memory Supported
256 GB
Memory Speed Supported
6400 MHz, 6200 MHz, 6000 MHz, 5800 MHz, 5600 MHz
Memory Technology
DDR5 SDRAM
Error Checking
ECC
Network & Communication
Gigabit Ethernet
Yes
2.5Gigabit Ethernet
Yes
Onboard Interfaces
Number of SATA Interfaces
4
Number of M.2 Interfaces
2
Total Number of Onboard USB Ports
5
Number of Onboard USB 2.0 Ports
2
Physical Characteristics
Form Factor
ATX
Height
1.4"
Width
9.6"
Depth
9.6"
Weight (Approximate)
1.85 lb
Processor & Chipset
Chipset Manufacturer
Intel
Chipset Model
Q870
Total Processor Supported
1
Processor Socket
Socket LGA-1851
Processor Supported
Core Ultra
Technical Information
AI-powered
Yes
Video
Onboard Video
CPU Dependent Video
Graphics Controller Manufacturer
Intel
Graphics Controller Model
HD Graphics
Warranty
Limited Warranty
3 Year
Miscellaneous
Environmental Compliance
Waste Electrical and Electronic Equipment Directive (WEEE), Taiwan Restriction of Hazardous Substances (Taiwan RoHS), China Restriction of Hazardous Substances (China RoHS), Restriction of Hazardous Substances (RoHS)
