Bixolon XM7-40 Mobile, Logistic, Field Service, Retail, Healthcare, POS System, Business, Outdoor, Warehouse Direct Thermal Printer - Monochrome - Label Print - USB - Serial - IEEE 802.11a/b/g/n Wireless LAN - Near Field Communication (NFC) - Battery Included
Bixolon

Bixolon XM7-40 Mobile, Logistic, Field Service, Retail, Healthcare, POS System, Business, Outdoor, Warehouse Direct Thermal Printer - Monochrome - Label Print - USB - Serial - IEEE 802.11a/b/g/n Wireless LAN - Near Field Communication (NFC) - Battery Included

TFT Display Screen - Peel Facility - 4.09" Print Width - 5 in/s Mono - 5 lps Mono - 203 dpi - SLCS, BPL-Z, BXL/POS, BPL-C, ZPL II, CPCL Emulation - For iOS, Android, PC

SKU
XM7-40WKL
Category
Label/Receipt Printers

Request pricing

Confirmed with stock and TAA status before any payment.

Request a quote

Genuine Bixolon through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
XM7-40WKL
Category
Label/Receipt Printers

Overview

Ultimate Printing Capability

• Fully compatible with SLCS, BPL-Z?, BPL-C? and BXL / POS : Interchanged without setting the mode

• Fast Liner & Linerless label printing

• Smart Media Detection

• Anywhere Anyfont (Unicode)

• Direct printing from the SAP® Smart Forms

• BIXOLON Profile Manager XPM?, XCM

Exceptional Mobility

• Smart battery providing visibility over status and life cycle

• Simultaneously connects both Bluetooth 5.0 (MFi certified) and Dual-band WLAN (2.4GHz and 5GHz)

• Supporting all major operating systems

• Easy Bluetooth Pairing

• SoftAP : Simple Wi-Fi set up to a mobile device

• Smart Connection - Switching from SoftAP to Infrastructure mode

Compact and Rugged Design

• Built with a large colour display for easy set-up and battery status management

• Embedded peeler and paper guide

• Up to 2.1 m / 7 ft. drop rate

• IP54 water and dust proof

• Enabling USB C-type charging

Highlights

  • Simultaneously connects both Bluetooth 5.0 and WLAN
  • Supports Easy Bluetooth Pairing via embedded NFC tag enabling auto pairing
  • Smart Connection - Switching from SoftAP
  • to Infrastructure mode
  • SoftAP : Simple Wi-Fi set up to a mobile device
  • Label Artist, Label Artist Mobile for iOS and Android

Specifications

Application/UsageMobile, Logistic, Field Service, Retail, Healthcare, POS System, Business, Outdoor, Warehouse
Barcode Symbology Supported1D, Codabar, Code 11, Code 39, Code 93, Code 128, EAN-13, EAN-8, Industrial 2 of 5, Interleaved 2 of 5, LOGMARS, MSI, Plessey, POSTNET, GS1 DataBar, Standard 2 of 5, UPC/EAN, UPC-E, IMB, 2D, AZTEC, Codablock, Code 49, Data Matrix, Maxi Code, Micro PDF-417, PDF-417, QR Code, TLC 39
Battery ChemistryLithium Ion (Li-Ion)
Package Contents
  • XM7-40 Direct Thermal Printer
  • Belt Strap
  • Smart Battery
  • SMPS
  • Power Cord
  • Paper Disk (Inner core : 12mm)
Product TypeDirect Thermal Printer
Display ScreenYes
Flash Memory256 MB
Manufacturer Part NumberXM740WKL
Media Thickness5.91 mil
Platform SupportediOS, Android, PC
Maximum Print Width4.09"
Power SourceBattery, USB
Recommended UseLabel Print
Maximum Roll Diameter2.60"
Standard Memory128 MB
Weight (Approximate)2.40 lb
Connectivity TechnologyWired & Wireless
FeaturesCompact, Rugged, Water Proof, Drop Resistant, Dust Proof, LCD Display, Ergonomic, Smart Battery Management
Language EmulationSLCS, BPL-Z, BXL/POS, BPL-C, ZPL II, CPCL
ManufacturerBixolon America, Inc
Product ModelXM7-40
Product NameXM7-40 Direct Thermal Printer
Product SeriesXM7
Brand NameBixolon
Operating System Supported
  • Microsoft Windows
  • Linux
  • Apple Mac
Media TypeLabel, Notch, Receipt, Linerless Label
Height3.2"
Width6.2"
Depth7.3"
Maximum Mono Print Speed5 in/s 5 lps
Battery Capacity6800 mAh
Battery IncludedYes
Wireless LANYes
Display Screen TypeTFT
Wireless LAN StandardIEEE 802.11a/b/g/n
Media SensorPaper End Sensor, Gap Sensor, Black Mark Sensor, Cover Open Sensor
USBYes
Serial PortYes
USB StandardUSB Type C
Wireless Print TechnologyWi-Fi Direct
Peel FacilityYes
Mobile Device PrintingYes
Print Color CapabilityMonochrome
Energy StarYes
Storage Temperature-22°F (-30°C) - 158°F (70°C)
Wi-Fi DirectYes
Optional ConnectivityBluetooth
Printing ColorBlack
Near Field Communication (NFC)Yes
Fonts Included10 SLCS, One SLCS, 16 BPL-Z, One BPL-Z, 7 BPL-C, 23 Code Page, Unicode supported (UTF-8, UTF-16LE, UTF-16BE)
Ingress Protection (IP) RatingIP54
Maximum Print Resolution (dpi)203
Operating Temperature5°F (-15°C) - 122°F (50°C)
Operating Relative Humidity10% - 80%
