Genuine Bixolon through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
XM7-40WK
Category
Label/Receipt Printers
Highlights
Direct Thermal Printer provides you with all the features that you need to print quickly and easily
203 maximum print resolution (dpi) for your convenience and easy usage
The printer is capable of printing sharp and detailed monochrome documents quickly
Enjoy the optimal performance in today's on-demand labeling applications
Bye bye Wires, Hello Wi-Fi! Cut down the potential hazards of tripping and electrical fires by reducing the number of long cables. Print wirelessly even from your mobile devices.
4.41" maximum label width for your convenience and feasible usability
Supports label media type for maximum feasibility and better accommodation of your requirements
Direct Thermal Printer with mobile application/usage provides maximum usability with better reliance
Tear Bar feature for maximum productivity with added dependability
LCD display is brighter with added efficiency, thinner, and feature better refresh rates
Specifications
Battery Information
Battery Included
Yes
Display & Graphics
Display Screen
Yes
Display Screen Type
LCD
Environmental Conditions
Operating Temperature
5°F (-15°C) - 122°F (50°C)
Operating Relative Humidity
10% - 80%
Storage Temperature
-22°F (-30°C) - 158°F (70°C)
General Information
Manufacturer
Bixolon America, Inc
Manufacturer Part Number
XM7-40WK
Brand Name
Bixolon
Product Series
XM7
Product Model
XM7-40
Product Name
XM7-40 Direct Thermal Printer
Product Type
Direct Thermal Printer
Interfaces/Ports
Serial Port
Yes
USB
Yes
Media Types & Handling
Media Type
Label, Notch, Receipt
Media Sensor
Transmissive Media Sensor, Paper End Sensor, Gap Sensor, Black Mark Sensor
Media Thickness
5.91 mil
Maximum Roll Diameter
2.60"
Maximum Label Width
4.41"
Network & Communication
Wi-Fi Direct
Yes
Wireless LAN
Yes
Wireless LAN Standard
IEEE 802.11a/b/g/n
Physical Characteristics
Product Color
Black
Height
3.2"
Width
6.2"
Depth
7.3"
Weight (Approximate)
12.70 oz
Power Description
Power Source
Battery
Reliability
Ingress Protection (IP) Rating
IP54
Software
Operating System Supported
Windows Driver (Europlus / Seagull), Linux / Mac CUPS Driver, Virtual COM USB Driver, Utility Program, LabelArtist-II?, Bartender UL, OPOS / JPOS Driver, SAP® Device Driver
Technical Information
Recommended Use
Label Print
Print Color Capability
Monochrome
Maximum Mono Print Speed
5 in/s
Maximum Print Resolution (dpi)
203
Maximum Print Width
4.09"
Barcode Symbology Supported
1D, Codabar, Code 11, Code 39, Code 93, Code 128, EAN-13, EAN-8, Industrial 2 of 5, Interleaved 2 of 5, LOGMARS, MSI, Plessey, POSTNET, GS1 DataBar, Standard 2 of 5, UPC/EAN, UPC-E, IMB, 2D, AZTEC, Codablock, Code 49, Data Matrix, Maxi Code, Micro PDF-417, PDF-417, QR Code, TLC 39
Fonts Included
10 SLCS, One SLCS, 16 BPL-Z, One BPL-Z, 7 BPL-C, 23 Code Page, Unicode supported (UTF-8, UTF-16LE, UTF-16BE)
Application/Usage
Mobile
Features
Tear Bar, LCD Display, Compact, Rugged, Water Proof, Dust Resistant, Drop Resistant
