Advantech IDP31-150P50HIB1 15" Class LCD Touchscreen Monitor - 16 ms
Advantech

Advantech IDP31-150P50HIB1 15" Class LCD Touchscreen Monitor - 16 ms

15" Viewable - Projected Capacitive - Multi-touch Screen - 1024 x 768 - XGA - 16.7 Million Colors - 500 Nit - LED Backlight - Speakers - DVI - HDMI - USB - VGA - 1 x HDMI In - Black - 2 Year

SKU
IDP31-150P50HIB1
Category
Touchscreen Monitors

$543.82

Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Advantech through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
IDP31-150P50HIB1
Category
Touchscreen Monitors

Overview

Introduction

The IDP31-150 Proflat monitor responds to a demand for contemporary styling in demanding applications such as public signage, front of house information, medical and point-ofsale. The product features a truly-flat, easy to clean and maintain glass surface with long term product availability. IDP31-150 can be used in either portrait or landscape mode and is cleverly packaged in such a way that no further mechanical parts are needed other than a VESA mount to create a display system. The use of a metal chassis provides a rugged and stable platform to build solutions for the widest range of applications.

Highlights

  • 15" LCD wide screen panel with LED backlight for long service life
  • Wide operating temperature -20 ~ +60 °C
  • Regular brightness 500 CD/m2
  • True flat surface - contemporary Proflat style
  • Wide view-angle for portrait and landscape mode
  • Built-in speakers
  • Thin profile, enclosure - no need for additional enclosures or metalwork
  • Multi-touch PCT touch with USB interface
  • Flexible signal interface: VGA, DVI & HDMI
  • Versatile mounting methods for front mounting and VESA mounting
  • Anti-Reflective surface treatment for sunlight readable enhancement (optional)
  • RS-232 port for remote control (optional)

Specifications

Package Contents
  • IDP31-150P50HIB1 Touchscreen LCD Monitor
  • 1 x M Cable USB-A(M)/USB-A(M) 180CM
  • 1 x VGA cable 15P(M) 1.8 meter
Product TypeLCD Touchscreen Monitor
Manufacturer Part NumberIDP31-150P50HIB1
Response Time16 ms
SpeakersYes
Limited Warranty2 Year
Touchscreen TypeProjected Capacitive
Weight (Approximate)8.82 lb
Brightness500 Nit
Color Supported16.7 Million Colors
ManufacturerAdvantech Co., Ltd
Product ModelIDP31-150P50HIB1
Product NameIDP31-150P50HIB1 Touchscreen LCD Monitor
Mount TypeFront Mount
Product SeriesIDP31-150
Viewable Screen Size15"
Maximum Resolution1024 x 768
Brand NameAdvantech
Screen ModeXGA
Country of OriginTaiwan
Height11"
Width14"
Depth1.7"
Environmentally FriendlyYes
USBYes
HDMIYes
Backlight TechnologyLED
VESA Mount CompatibleYes
Operating Power Consumption14 W
Native Contrast Ratio2,500:1
DVIYes
VGAYes
Number of USB Ports1
Number of HDMI Inputs1
Multi-touch ScreenYes
Screen Size Class15"
Product ColorBlack
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
