WatchGuard AP330 Dual Band IEEE 802.11ax 1.73 Gbit/s Wireless Access Point - Indoor
WatchGuard Technologies

WatchGuard AP330 Dual Band IEEE 802.11ax 1.73 Gbit/s Wireless Access Point - Indoor

2.40 GHz, 5 GHz - 6 x Internal Antenna(s) - Internal - MIMO Technology - 1 x Network (RJ-45) - 2.5 Gigabit Ethernet - PoE+ (RJ-45) Ports - 15.90 W

SKU
WGA33000000
Category
Wireless Access Points/Bridges

Request pricing

Confirmed with stock and TAA status before any payment.

Request a quote

Genuine WatchGuard Technologies through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
WGA33000000
Category
Wireless Access Points/Bridges

Overview

The AP 330 is WatchGuard's all-purpose Wi-Fi 6 access point and is the ideal choice for mid-density indoor environments of all sizes to utilize the most secure WPA3 encryption for a seamless experience. Includes 2x2 radio scanning optimized for Wi-Fi 6 with six internal antennas. Maximum TX power delivers 22 dBm and a 2dBi antenna gain with one Ethernet port supporting up to 2.5 Gbps. These Wi-Fi 6 access points deliver a maximum data rate for a seamless wireless experience by supporting up to 1.2 Gbps on the 5 GHz band and 574 Mbps available on the 2.4 GHz band. WatchGuard's AP130, AP330, AP430CR, and AP432 requires an active Management License. Select from a Standard or USP Management License to activate and access WatchGuard Cloud. The Management License is required to activate and manage the WatchGuard access points.

Highlights

  • Wi-Fi 6 and WPA3 encryption
  • Includes 2x2 radio optimized for Wi-Fi 6 with six omnidirectional internal antennas
  • PoE power includes 12V/2A DC In, 802.3at (PoE+)
  • Maximum TX power delivers 22 dBm and a 2 dBi antenna gain with one Ethernet port supporting up to 2.5 GBps
  • These Wi-Fi 6 access points deliver a maximum data rate for a seamless wireless experience by supporting up to 1201 Mbps on the 5 GHz band and 574 Mbps available on the 2.4 GHz band.

Specifications

Product TypeWireless Access Point
Manufacturer Part NumberWGA33000000
Limited Warranty1 Year
Weight (Approximate)1.87 lb
Network BandDual Band
ManufacturerWatchGuard Technologies, Inc
Product ModelAP330
Product NameAP330 Indoor Access Point
Power Consumption15.90 W
Wireless Transmission Speed1.73 Gbit/s
Brand NameWatchGuard
Height8.1"
Width8.1"
Depth1.3"
Frequency Band2.40 GHz, 5 GHz
Environmentally FriendlyYes
Antenna Form FactorInternal
Wireless LAN StandardIEEE 802.11ax
Encryption StandardWPA3
Ethernet Technology2.5 Gigabit Ethernet
USBYes
Number of Network (RJ-45) Ports1
Management PortYes
Total Number of Antennas6
Number of Internal Antennas6
Data EncryptionYes
MIMO TechnologyYes
PoE PD PortYes
Indoor/OutdoorIndoor
PoE+ (RJ-45) PortsYes
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
