Genuine Harman International Industries through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
NCDI2X300BL-U-US
Category
A/V Receivers & Amplifiers
Overview
The CDi DriveCore Series is an evolution in amplification, providing an impressive mix of high-performance; rich feature set, and competitive cost. Using technology derived from our flagship Installed Sound amplifier (Crown DriveCore Install series), the CDi DriveCore 2|300BL offers streamlined functionality to work in almost any small/medium sized installation such as restaurants, retail stores, and more. Designed for ease-of-use in a variety of applications, the 2|300BL is a 2-channel amp that includes network control/monitoring, high-level DSP, front-panel interface, and support for driving up to 100Vrms speaker loads without requiring a transformer. The 2|300BL also comes with BLU link, adding the ability to send and receive channels over HARMAN's digital audio BUS. The entire CDi DriveCore line comes pre-loaded with JBL speaker tunings to help make installations quicker and easier.
Warranty
Limited Warranty: 3 Year
Highlights
DriveCore Technology - Crown's proprietary DriveCore technology eliminates hundreds of components within each amplifier, reducing the variability of component values, increasing reliability, resulting in incredible audio fidelity from an efficient design.
Network Control and Monitoring - Through Harman's HiQnet Audio Architect software, the CDi DriveCore can be controlled, configured, and monitored through standard TCP/IQ network.
DSP - On-board Digital Signal Processor in each amplifier allows for custom configuration
Input Router
Input Delay - Up to 1000ms
Input Parametric EQ - 8 band
Crossover
Output Parametric EQ - 8 band
Output Delay - Up to 100ms
LevelMAX Limiter
Specifications
Audio
Audio Channels
2
RMS Output Power
600 W
General Information
Manufacturer
Harman International Industries, Inc
Manufacturer Part Number
NCDI2X300BL-U-US
Brand Name
Crown
Product Line
CDi DriveCore
Product Model
CDi 2|300BL
Product Name
Analog + BLU Link Input, 2 Channel, 300W per Output Channel
Product Type
Amplifier
Network & Communication
Ethernet
Yes
Physical Characteristics
Height
3.5"
Width
19"
Depth
12.3"
Weight (Approximate)
14.56 lb
Power Description
Input Voltage
120 V AC, 230 V AC
Operating Power Consumption
300 W
Technical Information
Minimum Frequency Response
20 Hz
Maximum Frequency Response
20 kHz
Total Harmonic Distortion (THD)
0.4%
Impedance
4 Ohm
Features
Digital Signal Processing
Warranty
Limited Warranty
3 Year
Miscellaneous
Environmentally Friendly
Yes
Environmental Compliance
Waste Electrical and Electronic Equipment Directive (WEEE)
