Genuine Elo Touch Solutions through authorized distribution — NDAA §889 screened before checkout.
SKU
Category
Digital Signage Systems
Overview
10-inch weather proof touchscreen that covers you from day to night.
Built to perform outdoors, Elo's 1099 weatherproof
monitor offers IP66 and NEMA 4X when integrated
into an enclosure as well as IK09 impact protection.
With extended operating temperatures from -20 to
60 degrees Celsius, the integrated outdoor digital
signage display can withstand harsh physical and
thermal requirements.
Sunlight readable monitor.
To provide unmitigated performance from day to night, the
ambient light sensor automatically adjusts the display's
brightness to optimize power consumption, extend the life
of the display and enhance the viewing experience.
Outdoor kiosk | solutions.
Elo's 1099L outdoor monitor enables
you to create reliable outdoor kiosks that
will capture audiences and differentiate
your sunlight readable outdoor display.
• Charging Stations
• Payment & Ticketing
• Vending Machine
• Human Machine Interface
• Order Pickup Lockers
Flexibility for your install.
Elo's waterproof touchscreen monitor can be mountedin landscape, portrait and upward facing orientations,providing optimal flexibility for integrating in anycounter, kiosk or cabinet design. Whether end users areviewing up close or from a distance, with or withoutpolarized sunglasses, our optically bonded outdoordigital signage display offers what you need whilemaintaining optimal clarity for the viewing experience.
Highlights
Digital Signage Kiosk offers a dependable video signage solution with maximum productivity
Experience luminescent visual images with LCD display
1280 x 800 display resolution for dependable display results with maximum efficiency
LED backlighting offers a fine uniformity to display effective pictures at a low cost
Specifications
Display & Graphics
Viewable Screen Size
10.10"
Display Screen Type
LCD
Multi-touch Screen
Yes
Touchscreen
Yes
Response Time
25 ms
Display Resolution
1280 x 800
Orientation
Landscape/Portrait
Backlight Technology
LED
Aspect Ratio
16:9
Maximum LED Life
5.7 Year
Environmental Conditions
Minimum Operating Temperature
-4°F (-20°C)
Maximum Operating Temperature
140°F (60°C)
Minimum Storage Temperature
-22°F (-30°C)
Maximum Storage Temperature
176°F (80°C)
Minimum Operating Humidity
10%
Maximum Operating Humidity
90%
Minimum Storage Humidity
10%
Maximum Storage Humidity
95%
General Information
Manufacturer
Elo Touch Solutions, Inc
Manufacturer Part Number
E354792
Brand Name
Elo
Product Model
1099L
Product Name
1099L Digital Signage Kiosk
Product Type
Digital Signage Kiosk
Interfaces/Ports
USB
Yes
HDMI
Yes
DisplayPort
Yes
Network & Communication
Ethernet
Yes
Physical Characteristics
Color Family
Black
Product Color
Black
VESA Mount Standard
200 x 100
Mount Type
Flush Mount, Bracket Mount
Height
6.9"
Width
10"
Depth
1.6"
Weight (Approximate)
4.85 lb
Power Description
Input Voltage
12 V DC, 24 V DC
Technical Information
Ingress Protection (IP) Rating
IP66
Impact Protection (IK) Rating
IK09
Panel Technology
Thin Film Transistor (TFT)
Operation Hours
24 Hours/7 Days
Video
Native Contrast Ratio
800:1
Brightness
1000 Nit
Miscellaneous
Application/Usage
Outdoor, Kiosk
Environmental Compliance
Restriction of Hazardous Substances (RoHS), China Restriction of Hazardous Substances (China RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
