Advantech HPC-8212 Server Case
Rack-mountable - 2U - 14 x Bay - 2 x 650 W - Power Supply Installed - EATX, ATX, Micro ATX Motherboard Supported - 2 x Internal 2.5" Bay - 12 x External 2.5"/3.5" Bay(s) - 6x Slot(s) - 2 x USB(s)
- SKU
- HPC-8212SE-R6A1E
- Category
- Computer Cases
$1,850.24
Back ordered — ships when restocked.
Genuine Advantech through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- HPC-8212SE-R6A1E
- Category
- Computer Cases
Overview
2U Storage Chassis for EATX/ATX/Micro ATX Serverboards with 12 Hot-Swappable Drive Bays
• 2U rackmount chassis supports EATX/ATX/uATX motherboard
• 12-bay hot-swappable 3.5"/2.5" SAS 12Gb/s drives or SATA 6Gb/s drives
• 4 x NVMe drives supported via an optional riser card
• Default 7x slots (low profile) rear panel, 3x slots (full height) optional
• Supports Flex ATX Power, 80+ redundant power supply
Highlights
- Supports EATX motherboard to provide a significant number of PCI slots, expansion slots and peripheral ports with enhanced heat dissipation capability
- 14 bays to add innumerable components and experience a peak computing performance
- Conveniently install in a rack and enables operational activities on the go
Specifications
| Product Type | Server Case |
|---|---|
| Manufacturer Part Number | HPC-8212SE-R6A1E |
| Motherboard Supported | EATX, ATX, Micro ATX |
| Weight (Approximate) | 55.12 lb |
| Form Factor | Rack-mountable |
| Manufacturer | Advantech Co., Ltd |
| Product Model | HPC-8212 |
| Product Name | HPC-8212 Server Case |
| Brand Name | Advantech |
| Country of Origin | China |
| Height | 3.5" |
| Width | 17.2" |
| Depth | 24.4" |
| Number of Fans Installed | 4 |
| Compatible Rack Unit | 2U |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 2 |
| Number of Internal 2.5" Bays | 2 |
| Power Supply Wattage | 650 W |
| Number of Total Expansion Bays | 14 |
| Total Number of USB Ports | 2 |
| Installed Fan Size | 3.15" |
| Total Number of Expansion Slots | 6 |
| Power Supply Installed | Yes |
| Number of External 2.5"/3.5" Bays | 12 |
