Advantech 4U Rackmount / Tower Chassis for EATX/ATX/MicroATX Motherboard
Advantech

Advantech 4U Rackmount / Tower Chassis for EATX/ATX/MicroATX Motherboard

Tower/Rack-mountable - 4U - 13 x Bay - 2 x 1200 W - Power Supply Installed - EATX, ATX, Micro ATX Motherboard Supported - 5 x Fan(s) Supported - 3 x External 5.25" Bay - 2 x Internal 2.5" Bay - 8 x External 2.5"/3.5" Bay(s) - 10x Slot(s) - 2 x USB(s)

SKU
HPC-7483-12RXE
Category
Computer Cases

$1,689.12

Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Advantech through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
HPC-7483-12RXE
Category
Computer Cases

Highlights

  • Supports EATX/ATX/MicroATX motherboard
  • Supports up to eight SATA3 or SAS3 hot-swap HDD
  • With the optional storage upgrade kit installed, the system will support up to eleven hot-swap HDD trays for higher storage requirements
  • Supports 80plus 1U 1+1 redundant high watt power supply
  • Supports up to ten FH/FL expansion slots

Specifications

Product TypeServer Case
Manufacturer Part NumberHPC-7483-12RXE
Motherboard SupportedEATX, ATX, Micro ATX
Weight (Approximate)44.09 lb
Form FactorTower/Rack-mountable
ManufacturerAdvantech Co., Ltd
Product ModelHPC-7483
Product Name4U Rackmount / Tower Chassis for EATX/ATX/MicroATX Motherboard
Brand NameAdvantech
Country of OriginChina
Height7"
Width17.1"
Depth25.9"
Number of Fans Supported5
Number of Fans Installed3
Number of External 5.25" Bays3
Compatible Rack Unit4U
Number of Power Supplies Supported2
Number of Power Supplies Installed2
Number of Internal 2.5" Bays2
Power Supply Wattage1200 W
Number of Total Expansion Bays13
Total Number of USB Ports2
Installed Fan Size4.72"
Total Number of Expansion Slots10
Power Supply InstalledYes
Number of External 2.5"/3.5" Bays8
