Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Oct 9 and Nov 13, then process your delivery right after.
Genuine Legrand through authorized distribution — NDAA §889 screened before checkout. TAA verified on request.
SKU
Category
Faceplates & Mounting Boxes
Country of origin
United States
Country of origin is manufacturer-reported and can vary by production lot. Where TAA applies to your purchase, we verify the shipping unit's origin on request.
Overview
Designed to fit into the 16" on center (406mm) opening between studs in a standard 2"x 4" (51mm x 102mm) wall. For both new work and old work applications. The box has 4-gang standard NEMA size openings and is designed to accommodate power, communications, and A/V devices. The box has been designed with a cable pass-through capability, allowing multiple service access points to be daisy chained together, eliminating the need for multiple conduit runs. Box includes temporary cover. Finished cover assembly (EHWB4C) sold separately.
Highlights
Available in both 4- and 8-gang versions to provide maximum flexibility.
Built-in tunnel & feed through capability allows service feeds to be fed through the box, reducing the number f feeds required to reduce installation time.
Cover opens a full 180° and can be painted to blend with room decor. Includes integrated handle, lock and key set for security, and flush egress door for cabling.
Designed to accept standard 1- to 4-gang device plates. No proprietary plates simplifies ordering and installation.
Accepts Legrand AVIP devices, plus A/V devices from leading manufacturers.
3 5/8" [92mm] of space behind device plates provides the extra depth needed for wiring larger A/V devices.
Accepts trade size service feeds from 3/4" up to 2". Knockout plates are removable and interchangeable, providing multiple options.
Can be installed in new work and old work installations. New hardware not necessary.
Both boxes (4- and 8-gang) fit are designed to fit in 16" opening between studs in standard 2" x 4" [51mm x 102mm] wall.
