Wireless Connectivity - 43.30" Scan Distance - 1D, 2D - LED - Imager - Area - , Radio Frequency - USB, Serial - Black, Yellow - Stand Included - IP65 - USB - Picking, Sorting, Industrial, Entertainment, Manufacturing, Warehouse, Logistics, Ticketing, Assembly Line, Component Tracking, Inventory
Request pricing
Confirmed with stock and TAA status before any payment.
Genuine Datalogic S.p.A through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
AIM, TRIGGER, DECODE: IT'S THAT SIMPLE!
An intuitive and effortless scanning experience is the target of the PowerScan 9501 series. They combine omnidirectional reading capabilities, typical in all area imaging scanners, with outstanding optical characteristics. The result is a scanner that is able to read any kind of bar code, regardless of the orientation, from contact to over 1.0 m / 3.3 ft, depending on the bar code resolution. In addition, Datalogic's latest decoding software guarantees snappy reading in any type of environment.
MOBILITY ENHANCES PRODUCTIVITY
The PowerScan 9501 further enhances operator efficiency and safety with Bluetooth wireless technology; no matter if you need 1 or 100 meters of freedom: you never need to worry about getting tangled up in the cable. Accurate power management allows long lasting battery life to always guarantee more than one shift of intensive scanning. Should you need to operate 24/7, a quick 3-second battery replacement combined with a single or multi-slot battery charger allows for continuous operation without interruption.
DEVELOPED WITH THE USER IN MIND
Handle shape, well-balanced weight and an intuitive aiming system allows high first-pass reading rates while reducing unnatural wrist movements for improved ergonomics and user comfort.
The PowerScan 9501 area imagers use a soft-pulsed white illumination light that is very gentle on the eyes and less troublesome to the operator during scanintensive applications.
BUILT TO LAST
The rugged mechanics of the PowerScan brand guarantees reliable, long term operation. Repeated shocks and indoor / outdoor usage in the toughest environmental conditions do not impact its performance or reliability.
Limited Warranty: 3 Year
| Battery Information | |
|---|---|
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Battery Capacity | 3350 mAh |
| Maximum Battery Recharge Time | 10 Hour |
| Environmental Conditions | |
| Operating Temperature | -4°F (-20°C) to 122°F (50°C) |
| Storage Temperature | -40°F (-40°C) to 158°F (70°C) |
| Humidity (Non-condensing) | 95% |
| General Information | |
| Manufacturer | Datalogic S.p.A |
| Manufacturer Part Number | PM9501-DHP910RBK20 |
| Brand Name | Datalogic |
| Product Line | PowerScan |
| Product Series | 9500 |
| Product Model | PM9501 |
| Product Name | PowerScan 9500 PM9501 Barcode Scanner Kit |
| Product Type | Barcode Scanner Kit |
| Interfaces/Ports | |
| Host Interface | USB, Serial |
| Network & Communication | |
| Radio Frequency | Yes |
| Physical Characteristics | |
| Form Factor | Handheld |
| Rugged | Yes |
| Color Family | Dual Color |
| Product Color | Black, Yellow |
| Durability | Water Resistant, Dust Resistant |
| Weight (Approximate) | 15.52 oz |
| Technical Information | |
| Connectivity Technology | Wireless |
| Scanning Capability | 1D, 2D |
| Barcode Symbology Supported | 1D: Autodiscriminates all standard 1D codes including GS1 DataBar linear codes. 2D: Aztec Code China Han Xin Code Data Matrix MaxiCode Micro QR Code QR Code Postal Codes: Australian Post China Post IMB Japanese Post KIX Post Planet Code Portuguese Post Postnet Royal Mail Code (RM4SCC) Swedish Post Stacked Codes: EAN/JAN Composites GS1 DataBar Composites GS1 DataBar Expanded Stacked GS1 DataBar Stacked GS1 DataBar Stacked Omnidirectional MacroPDF MicroPDF417 PDF417 UPC A/E Composites |
| Light Source | LED |
| Image Sensor Type | Imager |
| Scan Mode | Trigger |
| Scan Pattern | Area |
| Scanning Distance | 43.30" |
| Display Screen | Yes |
| Number of Keys | 4 |
| Cable Type Included | USB |
| Features | Beep, Notification LED, Ergonomic Design, 3GL |
| Stand Included | Yes |
| Reading Angle (Skew) | 40° |
| Reading Angle (Pitch) | 40° |
| Reading Angle (Roll) | 360° |
| Maximum Ambient Light | 100000 lux |
| Drop Specification |
|
| Minimum Print Contrast | 15% |
| Minimum Element Resolution (DataMatrix) | 4 mil |
| Maximum Element Resolution (DataMatrix) | 10 mil |
| Minimum Element Resolution (PDF417) | 10 mil |
| Image Sensor Resolution | 1280 x 1024 |
| Illumination Type | LED |
| Illumination Color | White |
| Air Electrostatic Discharge (+/-) | 20kV |
| Warranty | |
| Limited Warranty | 3 Year |
| Miscellaneous | |
| Package Contents |
|
| Ingress Protection (IP) Rating | IP65 |
| Application/Usage | Picking, Sorting, Industrial, Entertainment, Manufacturing, Warehouse, Logistics, Ticketing, Assembly Line, Component Tracking, Inventory |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS), Restriction of Hazardous Substances (RoHS), Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
