Datalogic PowerScan PBT9600 Barcode Scanner KIt
Wireless Connectivity - 1D, 2D - Imager - Omni-directional - Bluetooth - Serial, USB - Power Supply Included - IP65, IP67 - Serial - Manufacturing, Warehouse, Logistics, Picking, Inventory, Asset Tracking
- SKU
- PBT9600-ARRBK10US
- Category
- Barcode Scanners
Request pricing
Confirmed with stock and TAA status before any payment.
Genuine Datalogic S.p.A through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- PBT9600-ARRBK10US
- Category
- Barcode Scanners
Overview
ULTRA-RUGGED WITH NEW BALANCED ERGONOMICS!
The PowerScan family of bar code readers are the ultimate industrial handheld scanners designed and constructed to withstand the toughest environmental conditions. The PowerScan 9600 imagers have an ultrarugged design, an ergonomic shape with well-balanced weight to reduce operator stress during daily activities.
MOBILITY ENHANCES PRODUCTIVITY
The PowerScan PM9600 cordless model further enhances the operator efficiency and safety with Datalogic's STAR Cordless System?. Bidirectional radio communication and display allow users to receive immediate feedback avoiding any risk of mistakes. The PowerScan PBT9600 cordless model is enriched with Bluetooth® 5.0 that can be paired to any device supporting Bluetooth connections, or to the Bluetooth base station. The BC9600 base/charger has a modular design and is available with multiple interface plug-ins for standard and industrial communication, such as RS-232, USB, Standard Ethernet and Industrial Ethernet protocols.
WIRELESS CHARGING
The PowerScan 9600 scanner features Datalogic's Wireless Charging System. Based on inductive-charging technology, Datalogic's Wireless Charging System eliminates battery contacts and pins that often get dirty, bent, or broken over time - and this removes a key point of failure for devices used in industrial and retail functions.
THREE OPTIC OPTIONS TO FULFILL ANY CUSTOMER NEED
The PowerScan 9600 area imagers are available in three different optics, to satisfy any customer need. The Standard Range optic is ideal for most of the applications requiring barcode reading at intuitive distance; the High Performance optic adds the capability to decode high density barcodes together with an increased depth of field on standard 1D/2D codes; the Document Capture model is thought for Wide Angle code reading and Document Capture applications.
Highlights
- Reads all 1D barcodes with ease so you can accomplish all your tasks more efficiently
- Regardless of angle orientation, the imager makes it easy to scan 1D and 2D barcodes
- Increase productivity and performance by excluding the cable
- Bluetooth technology - Allows compatibility with most of your smart devices
Specifications
| Application/Usage | Manufacturing, Warehouse, Logistics, Picking, Inventory, Asset Tracking |
|---|---|
| Barcode Symbology Supported | 1D: Auto discriminates all standard 1D codes including GS1 DataBar? linear codes 2D: Aztec Code China Han Xin Code Data Matrix MaxiCode Micro QR Code QR Code Dot Code Postal Codes: Australian Post British Post China Post IMB Japanese Post KIX Post Planet Code Postnet Royal Mail Code (RM4SCC) Stacked Codes: EAN/JAN Composites GS1 DataBar Composites GS1 DataBar Expanded Stacked GS1 DataBar Stacked GS1 DataBar Stacked Omnidirectional MacroPDF MicroPDF417 PDF417 UPC A/E Composites Digital Watermarking: Digimarc Barcodes (HP and DC model |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Host Interface | Serial, USB |
| Product Type | Barcode Scanner Kit |
| Manufacturer Part Number | PBT9600-ARRBK10US |
| Weight (Approximate) | 15.70 oz |
| Connectivity Technology | Wireless |
| Form Factor | Handheld |
| Length | 5.5" |
| Manufacturer | Datalogic S.p.A |
| Product Model | PBT9600 |
| Product Name | PowerScan PBT9600 Barcode Scanner KIt |
| Product Line | PowerScan |
| Brand Name | Datalogic |
| Height | 7.8" |
| Width | 3.1" |
| Battery Capacity | 3350 mAh |
| Bluetooth | Yes |
| Scanner Range | Auto Range |
| Drop Specification |
|
| Scan Pattern | Omni-directional |
| Maximum Battery Recharge Time | 2.50 Hour |
| Image Sensor Type | Imager |
| Illumination Type | LED |
| Scan Mode | Trigger |
| Storage Temperature | -40°F (-40°C) to 158°F (70°C) |
| Power Supply Included | Yes |
| Illumination Color | Red |
| Ingress Protection (IP) Rating | IP65, IP67 |
| Rugged | Yes |
| Cable Type Included | Serial |
| Scanning Capability | 1D, 2D |
| Field of View (Horizontal) | 38° |
| Field of View (Vertical) | 24° |
| Reading Angle (Skew) | 60° |
| Reading Angle (Pitch) | 60° |
| Reading Angle (Roll) | 360° |
| Maximum Ambient Light | 100000 lux |
| Minimum Print Contrast | 20% |
| Minimum Element Resolution (Code 39) | 3 mil |
| Maximum Element Resolution (Code 39) | 20 mil |
| Minimum Element Resolution (DataMatrix) | 10 mil |
| Maximum Element Resolution (DataMatrix) | 100 mil |
| Operating Temperature | -4°F (-20°C) to 122°F (50°C) |
| Direct Part Marking (DPM) Decoding | Yes |
| Image Sensor Resolution | 1280 x 800 |
| Humidity (Non-condensing) | 0% to 95% |
