AddOn Juniper Networks® JNP-QSFP-100G-LR4-4WDM-40-I Compatible TAA 100GBase-4WDM-40 QSFP28 (SMF, 1295nm to 1309nm, 40km, LC, DOM, -40 to 85C)
AddOn

AddOn Juniper Networks® JNP-QSFP-100G-LR4-4WDM-40-I Compatible TAA 100GBase-4WDM-40 QSFP28 (SMF, 1295nm to 1309nm, 40km, LC, DOM, -40 to 85C)

For Data Networking, Optical Network - LC 100GBase-4WDM-40 Network - Optical Fiber - 1295 nm, 1309 nm Wavelength - Single-mode - 100 Gigabit Ethernet - 100GBase-4WDM-40 - 100 Gbit/s - 40 km Maximum Distance - Hot-swappable - 1 - TAA Compliant

SKU
JNPSP100GLR4WM40I-AO
Category
Modules

MSRP$21,000.00

$11,956.00

Save 43%

In stock: 16

Get a quote

Genuine AddOn through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
JNPSP100GLR4WM40I-AO
Category
Modules

Overview

This Juniper Networks JNP-QSFP-100G-LR4-4WDM-40-I compatible QSFP28 transceiver provides 100GBase-4WDM-40 throughput up to 40km over single-mode fiber (SMF) using a wavelength of 1295nm to 1309nm via an LC connector. It is capable of withstanding rugged environments and can operate at temperatures between -40 and 85C. Our transceiver is built to meet or exceed OEM specifications and is guaranteed to be 100% compatible with Juniper Networks. It has been programmed, uniquely serialized, and tested for data-traffic and application to ensure that it will initialize and perform identically. All of our transceivers comply with Multi-Source Agreement (MSA) standards to provide seamless network integration. Additional product features include Digital Optical Monitoring (DOM) support which allows access to real-time operating parameters. This transceiver is Trade Agreements Act (TAA) compliant. We stand behind the quality of our products and proudly offer a limited lifetime warranty.

Highlights

  • QSFP28 MSA compliant
  • Supports 103Gbps
  • Single 3.3V Power Supply and Power dissipation < 5W
  • Up to 40km over SMF with FEC on host
  • Operating case temperature: -40°C to 85°C
  • Four 25Gbps Cooled DFB-based LAN-WDM lasers on transmitter side
  • APD and TIA array on the receiver side
  • 4x25G electrical interface
  • Duplex LC receptacles
  • I2C interface with integrated Digital Diagnostic Monitoring

Specifications

Application/UsageData Networking, Optical Network
Product TypeQSFP28
CompatibilityMSA Compliant
Manufacturer Part NumberJNPSP100GLR4WM40I-AO
Maximum Distance Supported40 km
Packaged Quantity1
Interfaces/Ports DetailsLC 100GBase-4WDM-40 Network
Limited WarrantyLifetime
Weight (Approximate)0.20 lb
Connector TypeLC
FeaturesDigital Optical Monitoring (DOM)
Form FactorHot-swappable
ManufacturerAddOn
Product NameJuniper Networks QSFP28 Module
Network Technology100GBase-4WDM-40
Brand NameAddOn
Country of OriginUnited States/United Kingdom
Height0.4"
Width0.8"
Depth4.9"
Environmentally FriendlyYes
Maximum Data Transfer Rate100 Gbit/s
Ethernet Technology100 Gigabit Ethernet
Media Type SupportedOptical Fiber
Fiber Mode SupportedSingle-mode
TAA CompliantYes
Environmental ComplianceRestriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
Fiber Optic Cable Wavelength1295 nm, 1309 nm
