Advantech EKI-9528G-4GMX-A Ethernet Switch
Advantech

Advantech EKI-9528G-4GMX-A Ethernet Switch

Manageable - Gigabit Ethernet - 10/100/1000Base-T - 2 Layer Supported - 25 W Power Consumption - Wall Mountable, Enclosure

SKU
EKI-9528G-4GMX-A
Category
Switches & Bridges

MSRP$4,055.56

$3,207.09

Save 21%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Advantech through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
EKI-9528G-4GMX-A
Category
Switches & Bridges

Overview

Advantech's EKI-9528 series Ethernet switch delivers a ruggedized design with high EMC performance to rolling stock, wayside control, and other railroad applications. This solution leverages M12 connectors for Ethernet, console, relay, and power-input - ensuring excellent connectivity and endurance in harsh environments. EKI-9528 accommodates 12 different users' options. It provides 28 x ports Full Giga Ethernet or 16 x ports Fast Ethernet + 12 Giga (with 4 x Relay Bypass ports) with IEEE802.3af/at PoE function (PoE model only). PoE models deliver 150W of power to cameras, IP-phones, wireless access points, and other devices. In addition, Advantech's EKI-9528 series features an IP54 certified ruggedized housing and ample pitch connectors that connect/disconnect cables easily. This solution accommodates deployment in compact spaces and delivers mass Ethernet connection.

Highlights

  • M12 connector with ruggedized IP54 certified housing
  • Complies with EN50155 and EN50121-3-2 standards
  • 24 x PoE IEEE802.3af/at ports
  • Wide nominal power input range: 24 ~ 110VDC
  • Operating power input range: 16.8 ~ 137.5VDC
  • X-Ring Pro delivers rapid and predictable convergence
  • Leverages IXM technology to ease maintenance
  • Provides N-Key for quick configuration and backup ƒ Broad operating temperatures (-40 ~ 70 °C/-40 ~ 158 °F)
  • Fast Full Giga Ethernet solution

Specifications

Product TypeEthernet Switch
Input Voltage24 V DC, 110 V DC, 16.8 V DC, 137.5 V DC, 28 V DC, 36 V DC, 48 V DC, 72 V DC, 96 V DC
Manufacturer Part NumberEKI-9528G-4GMX-A
Power SourceDC
Layer Supported2
Weight (Approximate)14.11 lb
FeaturesBroadcast Storm Control, DHCP Snooping, Access Control List, Remote Monitoring (RMON), Support Dual Image, IP54
Form FactorWall Mountable, Enclosure
ManufacturerAdvantech Co., Ltd
Product ModelEKI-9528G-4GMX-A
Product NameEKI-9528G-4GMX-A Ethernet Switch
Network Technology10/100/1000Base-T
Power Consumption25 W
Product SeriesEKI-9528
Brand NameAdvantech
Height4.1"
Width11.8"
Depth4.1"
ManageableYes
Maximum Data Transfer Rate128 MB/s
Ethernet TechnologyGigabit Ethernet
Port/Expansion Slot Details28 x M12 8Pin X-Coded 10/100/1000BASE-T Gigabit Ethernet Network Port
Networking StandardsIEEE 802.1Q, IEEE 802.1ad, IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1p, IEEE 802.1x
Product MaterialDie-cast Aluminum, Die-cast Zinc
