Advantech EKI-2706G-1GFPI Ethernet Switch
Advantech

Advantech EKI-2706G-1GFPI Ethernet Switch

4 Ports - 2 Layer Supported - Modular - 1 SFP Slots - 2 W Power Consumption - 60 W PoE Budget - Twisted Pair, Optical Fiber - PoE Ports - DIN Rail Mountable, Wall Mountable - 5 Year Limited Warranty

SKU
EKI-2706G-1GFPI-BE
Category
Switches & Bridges

MSRP$308.00

$249.30

Save 19%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Advantech through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
EKI-2706G-1GFPI-BE
Category
Switches & Bridges

Overview

The EKI-2706 series support 48VDC redundant power input and is secured with a double protection mechanism: Power Polarity Reverse Protect and an Overload Current Fuse. The EKI-2706 series support up to 4-port IEEE 802.3 af/at PoE /PoE ports, it is more convenient for users to power up their devices. Each port of EKI-2706 has 2 LED's to show the link status transmission speed and collision status. It also provides a relay output for an event alarm. In the event of a power failure, the built-in LED will activate the alarm to notify administrators. Engineers can simply verify the hardware status by checking the LED, and have troubleshooting easy and quick. EKI-2706 comes with compact metal housing that rates IP30 to help against from dusty industrial environments.

Highlights

  • Supports 10/100/1000 Mbps Auto Negotiation (EKI-2706G)
  • Supports jumbo frame transmission up to 9 kbytes
  • DIN-rail with IP30 metal mechanism
  • Redundant 24~48 VDC power input(BE Version)
  • 4 x IEEE 802.3 af/at PoE ports + 1 x Gigabit Copper + 1 Gigabit SFP ports

Specifications

Product TypeEthernet Switch
Manufacturer Part NumberEKI-2706G-1GFPI-BE
Power SourcePower Supply, PoE
Limited Warranty5 Year
Layer Supported2
Form FactorDIN Rail Mountable, Wall Mountable
ManufacturerAdvantech Co., Ltd
Product ModelEKI-2706G-1GFPI
Product NameEKI-2706G-1GFPI Ethernet Switch
Network Technology10/100/1000Base-T, 1000Base-X
Power Consumption2 W
Product SeriesEKI-2706
Brand NameAdvantech
Expansion Slot TypeSFP (mini-GBIC)
Country of OriginChina
Height5.5"
Width1.2"
Depth3.7"
ManageableNo
Environmentally FriendlyYes
Ethernet TechnologyGigabit Ethernet
Number of SFP Slots1
ModularYes
Media Type SupportedTwisted Pair, Optical Fiber
Total Number of Network Ports4
PoE (RJ-45) PortYes
Port/Expansion Slot Details4 x Gigabit Ethernet PoE, 1 x Gigabit Ethernet Network, 1 x Gigabit Ethernet Expansion Slot
Total Number of Expansion Slots1.0
Redundant Power Supply SupportedYes
PoE Budget60 W
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
