SIIG Full HD HDMI Extender with IR - 164ft Over Cat5e/6
HDMI Extender over Cat5e/6 Extender Kit- Full HD 1080p up to 50m (164ft) - TX & RX - HDMI 1080p Extender over Cat5e Cat6 with IR - 10.2Gbps video bandwidth- HDCP 1.2- EDID Passthrough- IR Extension- Reset Button- 7.1-ch Audio- Wall Mountable- Aliminum Metal Housing - 2 years warranty
- SKU
- CE-H26111-S1
- Category
- Audio & Video Consoles/Extenders
MSRP$69.99
$65.87
Save 6%Back ordered — ships when restocked.
Genuine SIIG through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- CE-H26111-S1
- Category
- Audio & Video Consoles/Extenders
Overview
Extends HDMI audio/video signals up to 164ft over Cat5e/6 cable. Supports 480i/480p/720p/1080i/1080p at 60Hz resolutions
• Extends HDMI signals up to 164ft (50m) via a single cost effective CAT5e/6 networking cable, ideal for home theater, conference room or other audio/video applications that require remote location setup. Note : Extension over 100ft requires 100% copper Cat6 cable
• Delivers high-quality video/audio transmission without compression for optimal performance, supports video resolution up to 1080p@60Hz (Full HD), and 2-channel stereo audio, compatible with HDCP compliant devices and content, HDMI 1.3 and HDCP 1.2 compliant
• IR control allows your HDMI source device to recognize remote commands, you can control the HDMI source device from the remote location of your display device with the included IR cables that transmit signals over Cat cable
• Premium metal housing offers excellent heat dissipation, enhances durability, and minimizes EMI/RF interference for long life and dependable performance
• Easy installation, no driver installation is required, integrated surface mounting bracket allows secure placement
Notes :
• A good quality Cat5e/6 cable is essential in delivering quality content. Cat6 is recommended over Cat5e
• STP (Shielded Twisted Pair) cabling is recommended for cable runs over 50ft
• This extender pair (TX + RX) is point-to-point connection, it does not work through routers or switches
Highlights
- Video Extender Transmitter/Receiver is a reliable audio/video transmission extending solution
- 1920 x 1080 maximum video resolution for a spectacular, sharp display with added reliability
- HDMI in allows convenient transfer of content and data to video extender transmitter/receiver to ensure maximum dependability
- HDMI out enables you to transfer data from your devices to video extender transmitter/receiver with added efficiency
- Twisted pair media type is very easy to connect and can carry both analog and digital data at the same time for maximum connection efficiency
- 1 input devices supported for maximum productive usability
- 1 output devices supported to better accommodate your specific requirements
- 164.04 ft maximum operating distance for feasible operation and optimal coverage
- Full HD graphics mode provides optimal video output with remarkable picture clarity
Specifications
| Package Contents |
|
|---|---|
| Product Type | Video Extender Transmitter/Receiver |
| Manufacturer Part Number | CE-H26111-S1 |
| Limited Warranty | 2 Year |
| Connectivity Technology | Wired |
| Manufacturer | SIIG, Inc |
| Product Name | Full HD HDMI Extender with IR |
| Brand Name | SIIG |
| Country of Origin | China |
| Graphics Modes | Full HD |
| Environmentally Friendly | Yes |
| Maximum Video Resolution | 1920 x 1080 |
| Twisted Pair Cable Standard | Category 6 |
| Maximum Operating Distance | 164.04 ft |
| Number of Network (RJ-45) Ports | 2 |
| Network (RJ-45) | Yes |
| Number of HDMI Inputs | 1 |
| Number of HDMI Outputs | 1 |
| HDMI In | Yes |
| HDMI Out | Yes |
| Media Type Supported | Twisted Pair |
| Number of Output Devices Supported | 1 |
| Number of Input Devices Supported | 1 |
| Transmitter Height | 0.97" |
| Transmitter Width | 2.60" |
| Transmitter Depth | 2.80" |
| Receiver Height | 0.97" |
| Receiver Width | 2.60" |
| Receiver Depth | 2.80" |
| Transmitter Weight (Approximate) | 3.04 oz |
| Receiver Weight (Approximate) | 2.88 oz |
| Product Color | Black |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
