Lantronix SM24TBT2DPB Ethernet Switch
26 Ports - Manageable - Gigabit Ethernet - 10/100/1000Base-T, 1000Base-X - 4 Layer Supported - Modular - 2 SFP Slots - 52 W Power Consumption - Twisted Pair, Optical Fiber - Rack-mountable - 5 Year Limited Warranty
- SKU
- SM24TBT2DPB-NA
- Category
- Switches & Bridges
MSRP$2,915.00
$2,159.36
Save 26%Back ordered — ships when restocked.
Genuine Lantronix through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- SM24TBT2DPB-NA
- Category
- Switches & Bridges
Overview
(24) 10/100/1000Base-T Ports + (2) 100/1000Base-X SFP/RJ-45 Combo Ports
This switch is a high performance Layer 2 managed switch with 52 Gbps switching capacity. Itprovides (24) 10/100/1000Mbps copper ports with IEEE 802.3bt PoE++ capability and (2) additional100/1000Mbps dual speed SFP/RJ-45 combo ports. The SM24TBT2DPB complies with the latestIEEE 802.3bt PoE++ standard and supplies up to 90 Watts per port. It can provide full PoE++ outputon all 24 ports when equipped with the dual hot-swappable PS-ACDC-1200 power supplies. TheSM24TBT2DPB can be powered by low-line and high-line AC or DC power and Digital Electricity*,making it ideal for use in a wide variety of building applications.
Highlights
- Hot-swappable dual power supply modules
- Supports IPv4/IPv6 dual protocol stack
- Supports Jumbo Frame up to 9K bytes
- Authentication - RADIUS, TACACS+
- Security - Supports SSH v1/SSH v2/SSL
- Port based or tagged (IEEE 802.1Q) VLAN, MAC based, Management VLAN and Private VLAN Edge
- DHCP Relay, DHCP Server
- L2/L3/L4 ACLs Support MAC ACL, IP standard/extended ACL
- LLDP (Link Layer Discovery Protocol)
- IEEE 802.3az Energy Efficiency
- IP Source Guard, Port Security
Specifications
| Package Contents |
|
|---|---|
| Product Type | Ethernet Switch |
| Manufacturer Part Number | SM24TBT2DPB-NA |
| Power Source | PoE++, Power Supply |
| Limited Warranty | 5 Year |
| Layer Supported | 4 |
| Weight (Approximate) | 11.30 lb |
| Features | Hot-swappable |
| Form Factor | Rack-mountable |
| Manufacturer | Lantronix, Inc |
| Product Name | SM24TBT2DPB Ethernet Switch |
| Network Technology | 10/100/1000Base-T, 1000Base-X |
| Power Consumption | 52 W |
| Product Series | SM24TBT2DPB |
| Brand Name | Lantronix |
| Expansion Slot Type | SFP (mini-GBIC) |
| Height | 1.7" |
| Width | 17.4" |
| Depth | 11.8" |
| Manageable | Yes |
| Environmentally Friendly | Yes |
| Number of Power Supplies Supported | 1 |
| Ethernet Technology | Gigabit Ethernet |
| Network (RJ-45) | Yes |
| Number of SFP Slots | 2 |
| Modular | Yes |
| Stack Port | No |
| Media Type Supported | Twisted Pair, Optical Fiber |
| Total Number of Network Ports | 26 |
| Shared SFP Slot | Yes |
| Port/Expansion Slot Details | 24 x Gigabit Ethernet Network PoE++, 2 x Gigabit Ethernet Combo (Ethernet/SFP) |
| Total Number of Expansion Slots | 2 |
| Networking Standards | IEEE 802.3at, IEEE 802.1p, IEEE 802.3az, IEEE 802.3x, IEEE 802.1ab, IEEE 802.3af, IEEE 802.3bt, IEEE 802.3ae, IEEE 802.1s, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u, IEEE 802.1ad, IEEE 802.1D, IEEE 802.1w, IEEE 802.1Q, IEEE 802.3z |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH), Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE) |
