Eaton 5SC UPS 500VA 350 Watt 120V Line-Interactive Battery Backup Tower USB
Tower - 120 V AC Input - 4 x NEMA 5-15R
- SKU
- 5SC500
- Category
- General Purpose UPS
Request pricing
Confirmed with stock and TAA status before any payment.
Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- 5SC500
- Category
- General Purpose UPS
Overview
The flexible Eaton 5SC UPS delivers affordable and reliable protection for small business servers, storage and network equipment. The LCD interface provides clear status of UPS key parameters and allows configuration for output voltage, audible alarm and power input sensitivity. By using Eaton's Intelligent Power Manager software with the 5SC UPS you get up-to-the-minute information on the status of power in your network. The 5SC offers pure sinewave output for sensitive equipment as well as buck and boost operation to correct a wide range of input voltage variations without using batteries.
Warranty
Limited Warranty: 2 Year
About Eaton
We're dedicated to improving people's lives and the environment with power management technologies that are more reliable, efficient, safe and sustainable. Every day, all around the world, people depend on technology, transportation, energy and infrastructure to live and work. With rapid growth in electrification, an energy transition driven by climate change and explosive growth in connectivity, we’re well positioned to solve the world’s toughest electrical and mechanical power management challenges. Because that’s what really matters. And we’re here to make sure it works.
Highlights
- Enables you to customize UPS settings, view load and power consumption through the graphical interactive LCD screen interface
- Integrates with Intelligent Power Manager (IPM) for point-to-point power management (USB/serial) or network-based using server as a proxy. View Demo
- Offers user-replaceable batteries
- Extends battery service life by 50% with ABM technology
- Protects you with a three-year warranty, which includes the battery
- Corrects a wide range of input voltage variations through buck and boost operation
- Provides high quality pure-sinewave output capability, protecting any sensitive equipment connected ensuring consistent input voltage to the loads protected
Specifications
| Battery Chemistry | Lead Acid |
|---|---|
| Package Contents |
|
| Software Included | Eaton Intelligent Power Software |
| Product Type | Line-interactive UPS |
| Hot Swappable | No |
| Input Voltage | 120 V AC |
| Manufacturer Part Number | 5SC500 |
| Sound Emission | 55 dB |
| Limited Warranty | 2 Year |
| Output Voltage | 120 V AC |
| Weight (Approximate) | 15.21 lb |
| Form Factor | Tower |
| Manufacturer | Eaton Corporation |
| Product Name | 5SC UPS |
| Product Series | 5SC |
| Brand Name | Eaton |
| Plug/Connector Type | NEMA 5-15P |
| Country of Origin | Philippines |
| Cord Length | 5.91 ft |
| Height | 8.23" |
| Width | 5.91" |
| Depth | 9.45" |
| Receptacle Type | NEMA 5-15R |
| Environmentally Friendly | Yes |
| USB | Yes |
| Maximum Operating Temperature | 95°F (35°C) |
| Network (RJ-45) | Yes |
| Serial Port | Yes |
| Battery Characteristics | Maintenance-free, Sealed |
| Load Capacity (VA) | 500 VA |
| Load Capacity (Watt) | 350 W |
| Product Color | Black |
| Receptacle Detail | 4 x NEMA 5-15R |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
