SKU
ARK-2121L-U0A2E
Category
Desktop Computers
Overview
ARK-2000 series : Easy I/O Flexibility Fanless Embedded Computers
ARK-2000 series is an industrial modular embedded computer with rich I/O, intelligent edge computing, high flexibility and easy PCIe expansion capabilities, featuring wide-input power ranges, wide temperature ranges and structural strengthening, which is a perfect match with IoT platforms and scalable gateways.
Highlights
Intel® Celeron® J1900 Quad Core 2.0 GHz SoC with Turbo boost support
VGA and HDMI dual independent display
9 ~ 36 VDC wide range power input
-20 ~ 70° C extend temperature operating
Mini PCIe expansion with SIM holder for communication module
mSATA and 1 x 2.5" SATA storage device
Advantech iDoor module compatible
Advantech EMIO miniPCIe module compatible with all-in-one ordering
Specifications
Package Contents
ARK-2121L Desktop Computer
1 x User Manual (Simplified Chinese)
1 x China RoHS
1 x 2-pin Phoenix to DC-Jack Power Cable
Product Type
Desktop Computer
Manufacturer Part Number
ARK-2121L-U0A2E
Packaged Quantity
1
Weight (Approximate)
5.07 lb
Form Factor
Box PC
Manufacturer
Advantech Co., Ltd
Product Model
ARK-2121L
Product Name
ARK-2121L Desktop Computer
Processor Speed
2 GHz
Processor Type
Celeron
Product Series
ARK-2000
Brand Name
Advantech
Memory Technology
DDR3L SDRAM
Processor Model
J1900
Country of Origin
China
Height
2.7"
Width
10.4"
Depth
5.2"
Processor Core
Quad-core (4 Core)
Environmentally Friendly
Yes
Processor Manufacturer
Intel
Graphics Controller Manufacturer
Intel
Graphics Memory Technology
DDR3L SDRAM
Graphics Memory Accessibility
Shared
Ethernet Technology
Gigabit Ethernet
HDMI
Yes
VGA
Yes
Total Number of USB Ports
4
Number of USB 2.0 Ports
3
Number of USB 3.0 Ports
1
Maximum Turbo Speed
2.42 GHz
LAN Model
i210
Environmental Compliance
China Restriction of Hazardous Substances (China RoHS), Restriction of Hazardous Substances (RoHS)
