Taoglas Ultima MA111 Antenna
Taoglas

Taoglas Ultima MA111 Antenna

1710 MHz to 2170 MHz, 1850 MHz to 1990 MHz, 1710 MHz to 1880 MHz, 880 MHz to 960 MHz, 824 MHz to 896 MHz, 1574 MHz to 1606 MHz - 27 dB - Cellular Network, GPS, GLONASS, Wireless Data Network, Outdoor - White - Screw Mount - Omni-directional - SMA Connector

SKU
MA111.W.C.LB.001
Category
Antennas

MSRP$72.58

$68.29

Save 6%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Taoglas through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
MA111.W.C.LB.001
Category
Antennas

Overview

The MA111 Ultima Series 2in1 GPS/ GLONASS /GALILEO & Cellular Combination Antenna is a n extremely low profile combination high performance GPS /GLONASS /GALILEO and penta - band cellular antenna solution for professional telematics applications . At only 22 mm height it is the lowest profile antenna in the market, with a diameter of 55 mm. It is designed to be mounted and couple to the metal structures it attaches to radiate. Durable UV ABS housing, thread and nut is resistant to vandalism and direct attack.

The IP67 waterproof robust plastic body makes it extremely light, economical for shipping and minimum weight impact on vehicles. This also makes it ideal for use in humid environments such as water pits or marine applications as there are no external metal parts to corrode. The closed cell foam with double - sided adhesive provides a permanent waterproof seal and can adjust to different curvatures, stopping water from leaking under the antenna into the mounting hole.

Highlights

  • Height 19.6 mm (0.77")
  • Diameter 55 mm (2.17")
  • Heavy duty screw mount
  • UV and vandal resistant ABS housing and thread
  • IP67 compliance
  • GPS/GLONASS/GALILEO - 3M RG174 SMA(M)
  • Cellular - 3M CFD 200 SMA(M)
  • Customizable
  • ROHS Compliant

Specifications

Application/UsageCellular Network, GPS, GLONASS, Wireless Data Network, Outdoor
Product TypeAntenna
Manufacturer Part NumberMA111.W.C.LB.001
Packaged Quantity100
Weight (Approximate)7.14 oz
Connector TypeSMA
Form FactorScrew Mount
ManufacturerTaoglas
Product ModelMA111
Product NameUltima MA111 Antenna
Brand NameTaoglas
Diameter2.17"
Country of OriginTaiwan
Height0.77"
Environmentally FriendlyYes
Antenna Gain27 dB
DirectivityOmni-directional
Product ColorWhite
Operating Frequency Range1710 MHz to 2170 MHz, 1850 MHz to 1990 MHz, 1710 MHz to 1880 MHz, 880 MHz to 960 MHz, 824 MHz to 896 MHz, 1574 MHz to 1606 MHz
