Finisar SFP+ Module
Finisar

Finisar SFP+ Module

For Data Networking, Optical Network - 10GBase-SR/SW Network - Optical Fiber - Multi-mode - 10 Gigabit Ethernet - 10GBase-SR/SW0.40 m Maximum Distance - Hot-pluggable

SKU
FTLX8574D3BNL
Category
Modules

MSRP$229.15

$202.71

Save 12%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Finisar through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
FTLX8574D3BNL
Category
Modules

Overview

Finisar's FTLX8574D3BNL Extended Temperature 10Gb/s SFP+ transceivers are designed for use in 10-Gigabit Ethernet links over multimode fiber. They are compliant with SFF-84311 , SFF-84322 , IEEE 802.3-2012 10GBASE-SR/SW3 and 10G Fibre Channel 1200-Mx-SN-I4 . Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-84725 . The FTLX8574D3BNL is a "limiting module", i.e., it employs a limiting receiver. Host board designers using an EDC PHY IC should follow the IC manufacturer's recommended settings for interoperating the host-board EDC PHY with a limiting receiver SFP+ module. The optical transceiver is compliant per the RoHS Directive 2011/65/EU6.

Highlights

  • Hot-pluggable SFP+ footprint
  • Supports 9.95 to 10.5 Gb/s bit rates
  • Power dissipation < 1W
  • RoHS-6 compliant (lead-free)
  • Commercial temperature range -5°C to 85°C
  • Single 3.3Vpower supply
  • Maximum link length of 400m on OM4 MMF
  • Uncooled 850nm VCSEL laser
  • Receiver limiting electrical interface
  • Duplex LC connector
  • Built-in digital diagnostic functions

Specifications

Application/UsageData Networking, Optical Network
Product TypeSFP+
Manufacturer Part NumberFTLX8574D3BNL
Maximum Distance Supported0.40 m
Interfaces/Ports Details10GBase-SR/SW Network
Connector TypeLC
Form FactorHot-pluggable
ManufacturerFinisar Corporation
Product NameSFP+ Module
Network Technology10GBase-SR/SW
Brand NameFinisar
Environmentally FriendlyYes
Ethernet Technology10 Gigabit Ethernet
Media Type SupportedOptical Fiber
Fiber Mode SupportedMulti-mode
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
