Tripp Lite by Eaton Cisco-Compatible SFP-25G-LR-S SFP28 Transceiver - 25GBase-SR, Singlemode LC, 1310 nm, 10 km (6.2 mi.)
Eaton

Tripp Lite by Eaton Cisco-Compatible SFP-25G-LR-S SFP28 Transceiver - 25GBase-SR, Singlemode LC, 1310 nm, 10 km (6.2 mi.)

For Optical Network, Data Networking - 1 LC Female Duplex 25GBase-SR Network - Optical Fiber Single-mode - 25 Gigabit Ethernet - 25GBase-SR - Hot-swappable

SKU
N286-25G-LR-S
Category
Modules

MSRP$1,355.65

$512.80

Save 62%

In stock: 40

Get a quote

Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
N286-25G-LR-S
Category
Modules

Overview

SFP28 Transceiver Designed for Connection to Your Cisco Network Switch or Server

This SFP28 transceiver allows you to connect a singlemode fiber optic cable to a 25 Gbps network router, server or switch. It transmits data up to 10 kilometers (6.2 miles) using a 1310 nm wavelength. The zinc housing protects against electromagnetic interference (EMI) and excessive power dissipation.

Functionally Equivalent to Cisco SFP-25G-LR-S Transceiver Module

The MSA-compliant N286-25G-LR-S functions just like the equivalent Cisco SFP-25G-LR-S transceiver module and is manufactured to meet or exceed Cisco specifications. You can use this transceiver with any compatible Cisco router, server or switch and receive the same performance as the SFP-25G-LR-S.

Hot-Swappable for Installation Without Network Interruption

This input/output device is fully hot-swappable, so you can install it without a potentially costly 25 Gbps network shutdown or device reboot. Just plug the SFP28 end of the transceiver into your Cisco network device. The other end has an LC duplex connector to link with singlemode fiber optic cable (sold separately). A push/pull tab connector is easily accessible in high-density data center applications and makes the plug-and-play transceiver easy to install and remove with one hand.

Warranty

Limited Warranty: 3 Year

About Eaton

Eaton is an intelligent power management company dedicated to improving the quality of life and protecting the environment for people everywhere. We are guided by our commitment to do business right, to operate sustainably and to help our customers manage power ─ today and well into the future. By capitalizing on the global growth trends of electrification and digitalization, we're accelerating the planet's transition to renewable energy and helping to solve the world's most urgent power management challenges.

Highlights

  • SFP28 transceiver module 100% compatible with Cisco's equivalent module
  • Provides 25 Gbps throughput up to 10 kilometers (6.2 mi.) via singlemode fiber cabling
  • LC duplex female connector supports 25GBase-SR signal at 1310 nm wavelength
  • Hot-swappable interface lets you install and uninstall without shutting down
  • Meets or exceeds MSA standards and works in all MSA-compliant platforms
  • 3-year limited warranty

Specifications

Application/UsageOptical Network, Data Networking
Product TypeSFP28
CompatibilityMSA Compliant
Manufacturer Part NumberN286-25G-LR-S
Interfaces/Ports Details1 x LC Duplex 25GBase-SR Network
Limited Warranty3 Year
Connector TypeLC
Form FactorHot-swappable
ManufacturerEaton Corporation
Product NameCisco SFP28 Module
Network Technology25GBase-SR
Brand NameTripp Lite series
Country of OriginChina
Height0.3"
Width0.5"
Depth2.2"
Environmentally FriendlyYes
Ethernet Technology25 Gigabit Ethernet
Media Type SupportedOptical Fiber
Fiber Mode SupportedSingle-mode
Total Number of Ports1
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
