WD Ultrastar Serv60+8 Hybrid Storage Server
Intel Xeon - 60 x HDD Supported - 780 TB Supported HDD Capacity - 24 x HDD Installed - 336 TB Installed HDD Capacity - 32 x SSD Supported - Serial Attached SCSI (SAS) Controller - 68 x Total Bays - 8 x 2.5" Bay - 60 x 2.5"/3.5" Bay - 6 x Total Slot(s) - 10 Gigabit Ethernet - VGA - 4 USB Port(s) - 2 USB 2.0 Port(s) - 2 USB 3.0 Port(s) - Network (RJ-45) - IPMI 2.0 - 4U - Rack-mountable
- SKU
- 1ES1365
- Category
- Storage Arrays & Servers
$25,293.14
Back ordered — ships when restocked.
Genuine Western Digital through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- 1ES1365
- Category
- Storage Arrays & Servers
Overview
Designed for High Density and Flexibility
The Ultrastar Serv60+8 Hybrid Storage Server has dual high-performance Intel® Xeon® scalable processor-based CPUs to manage the demanding workloads in Software-Defined Storage (SDS) environments. With a choice of CPUs, memory, and drives, it balances performance with cost.
The Ultrastar Serv60+8 hybrid storage server addresses the demanding needs of large enterprise customers, OEMs, cloud service providers, as well as systems integrators that require dense, shared HDD or hybrid storage with compute included.
Designed for Big Data
High Density
Up to 780TB raw capacity in a 4U enclosure
Hybrid
Support for up to 32 SSDs within the server for a data acceleration tier
Innovative
IsoVibe and ArcticFlow for improved reliability, cooling, and TCO
Highlights
- High-performance Intel Xeon® scalable processor-based server
- Choice of CPUs to match workloads
- Up to 60 (SAS or SATA) HDDs plus up to 8 (SAS or SATA) SSDs
- Hybrid support with up to 24 SSDs (SAS or SATA) in place of HDDs for a data acceleration tier
- Up to 780TB raw capacity in a 4U enclosure; up to 195TB per rack unit.
- Enterprise-grade redundant and hot-swappable PSUs and fans
- 5-year limited warranty
Specifications
| Product Type | NAS Storage System |
|---|---|
| Manufacturer Part Number | 1ES1365 |
| Protocols | IPMI 2.0 |
| Limited Warranty | 5 Year |
| Form Factor | Rack-mountable |
| Manufacturer | Western Digital Corporation |
| Product Name | Ultrastar Serv60+8 Hybrid Storage Server |
| Processor Type | Xeon |
| Product Line | Ultrastar Serv60+8 |
| Controller Type | Serial Attached SCSI (SAS) |
| Rack Height | 4U |
| Brand Name | WD |
| Expansion Slot Type | PCI Express 3.0 x8 |
| Height | 6.9" |
| Width | 17.6" |
| Depth | 43.3" |
| Processor Manufacturer | Intel |
| Number of Power Supplies Installed | 2 |
| Redundant Power Supply | Yes |
| Ethernet Technology | 10 Gigabit Ethernet |
| Number of Total Expansion Bays | 68 |
| VGA | Yes |
| Network (RJ-45) | Yes |
| Maximum Power Supply Wattage | 2000 W |
| Total Number of USB Ports | 4 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.0 Ports | 2 |
| Total Hard Drive Capacity Supported | 780 TB |
| Total Hard Drive Capacity Installed | 336 TB |
| Number of Hard Drives Supported | 60 |
| Number of Hard Drives Installed | 24 |
| Number of Solid State Drive Supported | 32 |
| Number of Solid State Drive Installed | No |
| Number of 2.5" Bays | 8 |
| Number of 2.5"/3.5" Bays | 60 |
| Drive Interface | Serial Attached SCSI (SAS) |
| Total Number of Expansion Slots | 6 |
