WD Ultrastar Serv60+8 Hybrid Storage Server
Western Digital

WD Ultrastar Serv60+8 Hybrid Storage Server

Xeon - 60 x HDD Supported - 780 TB Supported HDD Capacity - 60 x HDD Installed - 720 TB Installed HDD Capacity - 32 x SSD Supported - Serial Attached SCSI (SAS) Controller - 68 x Total Bays - 8 x 2.5" Bay - 60 x 2.5"/3.5" Bay - 6 x Total Slot(s) - 10 Gigabit Ethernet - VGA - 4 USB Port(s) - 2 USB 2.0 Port(s) - 2 USB 3.0 Port(s) - Network (RJ-45) - IPMI 2.0 - 4U - Rack-mountable

SKU
1ES1268
Category
Storage Arrays & Servers

$36,398.82

Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Western Digital through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
1ES1268
Category
Storage Arrays & Servers

Overview

Designed for High Density and Flexibility

The Ultrastar Serv60+8 Hybrid Storage Server has dual high-performance Intel® Xeon® scalable processor-based CPUs to manage the demanding workloads in Software-Defined Storage (SDS) environments. With a choice of CPUs, memory, and drives, it balances performance with cost.

The Ultrastar Serv60+8 hybrid storage server addresses the demanding needs of large enterprise customers, OEMs, cloud service providers, as well as systems integrators that require dense, shared HDD or hybrid storage with compute included.

Designed for Big Data

High Density

Up to 780TB raw capacity in a 4U enclosure

Hybrid

Support for up to 32 SSDs within the server for a data acceleration tier

Innovative

IsoVibe and ArcticFlow for improved reliability, cooling, and TCO

Highlights

  • High-performance Intel Xeon® scalable processor-based server
  • Choice of CPUs to match workloads
  • Up to 60 (SAS or SATA) HDDs plus up to 8 (SAS or SATA) SSDs
  • Hybrid support with up to 24 SSDs (SAS or SATA) in place of HDDs for a data acceleration tier
  • Up to 780TB raw capacity in a 4U enclosure; up to 195TB per rack unit.
  • Enterprise-grade redundant and hot-swappable PSUs and fans
  • 5-year limited warranty

Specifications

Product TypeNAS Storage System
Manufacturer Part Number1ES1268
ProtocolsIPMI 2.0
Limited Warranty5 Year
Weight (Approximate)210 lb
Form FactorRack-mountable
ManufacturerWestern Digital Corporation
Product NameUltrastar Serv60+8 Hybrid Storage Server
Processor TypeXeon
Product LineUltrastar Serv60+8
Controller TypeSerial Attached SCSI (SAS)
Rack Height4U
Brand NameWD
Expansion Slot TypePCI Express 3.0 x8
Height6.9"
Width17.6"
Depth43.3"
Number of Power Supplies Installed2
Redundant Power SupplyYes
Ethernet Technology10 Gigabit Ethernet
Number of Total Expansion Bays68
VGAYes
Network (RJ-45)Yes
Maximum Power Supply Wattage2000 W
Total Number of USB Ports4
Number of USB 2.0 Ports2
Number of USB 3.0 Ports2
Total Hard Drive Capacity Supported780 TB
Total Hard Drive Capacity Installed720 TB
Number of Hard Drives Supported60
Number of Hard Drives Installed60
Number of Solid State Drive Supported32
Number of Solid State Drive InstalledNo
Number of 2.5" Bays8
Number of 2.5"/3.5" Bays60
Drive InterfaceSerial ATA
Total Number of Expansion Slots6
