HGST 4U60G2 Drive Enclosure - 12Gb/s SAS Host Interface - 4U Rack-mountable
Western Digital

HGST 4U60G2 Drive Enclosure - 12Gb/s SAS Host Interface - 4U Rack-mountable

60 x HDD Supported - 720 TB Total HDD Capacity Supported - 12 x SSD Supported - 60 x Total Bay

SKU
1ES1095
Category
Drive Cabinets

$32,149.89

Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Western Digital through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
1ES1095
Category
Drive Cabinets

Overview

The HGST 4U60G2 Storage Platform is the ideal choice for high-capacity storage needs. The Platform delivers a set of unique advantages:

• 96TB-720TB in just 4U of rack height

• Enterprise-class serviceability and availability

• Integrated platform enables fast time-to-deployment

• Qualified, tested and certified with a broad range of HGST HDDs

The HGST 4U60G2 Storage Platform is highly scalable and cost effective. With 12Gb/s SAS interface and HDD-SSD hybrid capability, the Platform is designed for data centers that need a dense solution with HA capabilities, while maintaining a low power profile.

Highlights

  • Up to 60 integrated Ultrastar® drive modules: 4U60G2: available drive module capacity1 includes 12TB, 10TB, 8TB, and 6TB; 4U60: available drive module capacity includes 10TB, 8TB, 6TB and 4TB
  • Hybrid capability: can be configured with up to 12 800GB SSDs to create separate performance tiers within the platform
  • Available with SAS drives for HA applications
  • Available with 512e or 4Kn sector size (by part number)
  • Supports up to 4 storage enclosures for daisy-chaining3
  • Host connectivity: 4U60G2: 4 x HD Mini-SAS ports per IO Module; 4U60: 2 x QSFP+ per IO Module
  • Fully compliant with 12Gb/s SAS 3 interconnect
  • Hot-swappable components: two power supplies with integrated fans, drive modules, and IO Modules
  • Cable Management Arm (CMA) eliminates tangled cables during servicing of hot-swappable CRUs
  • SCSI Enclosure Services (SES-3)

Specifications

Host Interface12Gb/s SAS
Product TypeDrive Enclosure
Manufacturer Part Number1ES1095
Limited Warranty5 Year
Form FactorRack-mountable
ManufacturerWestern Digital Corporation
Product Model4U60G2
Product Name4U60G2 Storage Platform
Rack Height4U
Brand NameHGST
Height6.9"
Width16.7"
Depth34.7"
Number of Total Expansion Bays60
Total Hard Drive Capacity Supported720 TB
Total Hard Drive Capacity Installed600 TB
Number of Hard Drives Supported60
Number of Hard Drives Installed60
Number of Solid State Drive Supported12
Number of Solid State Drive InstalledNo
Cooling FanYes
